7
6.5.1 Start Screen
SP XFLO W
VX.X.X
Basic Menu
If there is a PDP sensor, the first line indicates the pressure dew
point; if there is no sensor, the first line is empty!
Dryer On, without PDP-Sensor
Dryer On, with PDP-Sensor (Option)
-5 8°F
Dryer Off, without PDP-Sensor
Dryer Off, with PDP-Sensor (Option)
-5 8°F
Press
to move to:
Shows hours with operating voltage
48h
Press
to move to:
Shows the hours until the next service
1 320 h
Press
to move to:
Shows the software version
V 1 .0 .0
Press
to move to:
Dryer On, without PDP-Sensor
or after approx. 1 minute without input.
6.5.2 Message History
By briefly pressing , you get to the message display.
Press again briefly to return to "Basic menu", or after
2 minutes and 30 seconds.
The messages are numbered at the top right (1 is the latest,
maximum 20 messages, fifo system)
Press
to scroll through the messages .:
- Warnings cause the warning / service relay to drop.
- Alarms cause the alarm relay to drop.
Possible messages:
202
Drain Warning (deactivates the Relay warning /
service) yellow LED flashes
310
Service time expired
Relay warning / service) yellow LED glows
204
DTP alarm (deactivates the Relay Alarm)
red LED flashes
210
DTP sensor cable break deactivates the Relay
Alarm) red LED lights
If power failure message 204 is suppressed for 10 minutes,
message 202 is also suppressed.
Examples:
1st Message (newest)
Message 202, at 2891 hours with operating voltage
1
2 02 2 8 9 1 h
5. Message (5 newest)
Message 310, at 2602 hours with operating voltage
5
3 10 2 6 0 2 h
12. Message (12 newest)
Message 204, at 2001 hours with operating voltage
1 2
2 04 2 0 0 1 h
18. Message (18 newest)
Message 210, at 308 hours with operating voltage
1 8
2 10 3 08 h
