19
Logged data on the edge® can be transferred from the meter to a PC by
following these simple directions. Suitable operating systems include Windows
(Xp minimum), OS X or Linux.
1. Connect edge® to the PC using the supplied micro USB cable.
2. Turn on edge®.
3. Press SETUP and select “LOG ON EDGE”
4. Press MODIFY then use pq keys to change to “EXPORT TO USB”
5. Press CFM and the USB/PC Tag is displayed.
6. Press SETUP to exit
The PC should detect the USB as a removable drive. Open the drive to view the
stored les. Log les are formatted as Comma separated values (*.CSV) and can
be opened with any text editor or spreadsheet program. (Note: Field separator
may be set as comma or semicolon depending upon region preferences, see
Setup.)
Note:
• Western Europe (ISO-88859-1) character set and English language are
suggested settings.
• Other les may be visible depending upon computer settings. All les
stored will appear in this folder.
• Adjust Font or column width appropriately. Adjust the decimal places if the
pH was logged with 0.001 resolution.
• All conductivity measurements will be displayed as μS/cm.
Interval logs are designated as pH, EC or DO Lots. ie. PHLOT001, ECLOT002,
DOLOT003.
The Manual Lots are PHLOTMAN, ECLOTMAN, and DOLOTMAN.
The Stability Lots are PHLOTSTA, ECLOTSTA, and DOLOTSTA. All stability logs,
regardless of stability setting, are located in the same stability le for that
measurement.
Click on the desired log to view data.
Note:
• If “ºC !” appears in log data, the electrode/probe was used beyond it’s
operation specications and the data is not considered reliable.
• If “ºC !!” appears in log data, the temperature sensor within the probe or
electrode is broken and the device should be replaced. Logged data should
not be considered reliable.
PC & Storage
Interface
