Hansa C16 O&M Manual - OM-009 Revision G 26/09/2019
© Hansa Chippers 2019
Bolt the wheels on, then screw the wheel nuts
on, ensuring the rounded side of the nuts taper
into the steel rim.
Tighten the nuts using a 19 mm socket, then
torque them to 80 N.m.
Lightly grease the flange on the chipper body.
Slide the outlet chute onto the greased flange
of the chipper body, ensuring that the locking
hinge is open.
Close the locking hinge and tighten the outlet
chute locking handle to secure the outlet chute
to the chipper body.
Note: The outlet chute locking handle will be in
the documentation package.
