Clock display symbols
The oven is switched on or ready
for use.
Set the cooking time, or the cooking
time is set.
Heat symbol lights up when the oven
is heating.
Set shutdown time, or the shutdown
time is set.
8.8.8.8.
:
OK
(10) (11) (12) (14) (15) (16)(13)
(18) (17)
(19)
Control panel
(10) Temperature controller for front left
cooking zone
(11) Temperature controller for back left
cooking zone
(12) Oven dial
(13) Clock
(14) Temperature controller for the oven
(15) Temperature controller for back right
cooking zone
(16) Temperature controller for front right
cooking zone
(17) Indicator light
(18) OK button
(19) Arrow buttons
Hob
(20) Front left cooking zone
(21) Back left cooking zone
(22) Back right cooking zone
(23) Front right cooking zone
(24) Residual heat display
Oven
(25) Carrying handle
(26) Extraction hood (ventilation)
(27) Telescopic oven rails
(28) Oven rack guides
(25)
(20)
(21)
(22)
(23)
(24)
(26)
(27)
(28)
