Hantek DSO2000 Series User Manual

66 / 72
➢ The oscilloscope must be within the factory calibration interval.
All specifications are guaranteed unless noted ‘typical’.
Oscilloscope Specifications
Horizontal
SEC/DIV Range
2ns/div to 100s/div, in a 1, 2, 5 sequence
Delta Time Measurement Accuracy
(Full Bandwidth)
Single, sampling mode
± (1 sample interval +100ppm × reading + 0.6ns)
＞16 times above average
± (1 sample interval + 100ppm × reading + 0.4ns)
Sample interval = s/div ÷ 200
Vertical
A/D Converter
8-bit resolution, each channel sampled simultaneously
VOLTS/DIV Range
2mV/div to 10V/div at input BNC
Offset Range
2mV~200mV/div, ±1V
500mV/div~10V/div, ±50V
Selectable Analog Bandwidth Limit,
typical
20MHz
Low Frequency Response (-3db)
≤10Hz at BNC
Rise Time at BNC, typical
DSO2C10
DSO2C15
DSO2D10
DSO2D15
≤3.5ns
≤2.4ns
≤3.5ns
≤2.4ns
DC Gain Accuracy
±3% for Normal or Average acquisition mode, 10V/div to 10mV/div
±4% for Normal or Average acquisition mode, 5mV/div to 2mV/div
Vertical offset accuracy
±0.1div±2mV±1% Offset
Note: Bandwidth reduced to 6MHz when using a 1X probe.
Acquisition
Sample Rate Range
1GS/s (Single-channel); 500MSa/s (Dual-channel);
Acquisition Modes
Normal, Peak, Average and High Resolution
Waveform Interpolation
(sin x)/x
Acquisition Rate, typical
Up to 2000 waveform per second per channel (Normal acquisition mode, no
measurement)
Minimum detection pulse width
2ns
Single Sequence
Acquisition Mode
Acquisition Stop Time
Normal,
Peak Detect
Upon single acquisition on all channels simultaneously
Average
After N acquisitions on all channels simultaneously, N
can be set to 4, 8, 16, 32, 64 or 128
Memory depth
Maximum 8M for single channel (4K, 40K, 400K, 4M, 8M optional)
Maximum 4M for dual channels (4K, 40K, 400K, 4M optional)
Trigger
