Hantek DSO2000 Series User Manual

67 / 72
Mode
Auto, Normal, single
Level
CH1~CH2
±5 divisions from center of screen
EXT
3.3V [CMOS]
Holdoff Range
20ns ~ 10s
Trigger Level Accuracy
CH1~CH2
0.2div × volts/div within ±4 divisions from center of screen
Trigger sensitivity
±0.2div
Edge Trigger
Slope
Rising, Falling, Rising&Falling
Source
CH1~CH2, Line, External
Pulse Trigger
Polarity
Positive, Negative
Condition
<, >, !=, =
Source
CH1~CH2
Width Range
8ns ~ 10s
Video Trigger
Signal Standard
NTSC, PAL
Source
CH1~CH2
Sync
ScanLine, LinrNum, OddField, EvenField and AllField
Slope Trigger
Slope
Rising, Falling
Condition
<, >, !=, =
Source
CH1 ~ CH2
Time Range
8ns ~ 10s
Overtime Trigger
Source
CH1~CH2
Polarity
Positive, Negative
Time Range
8ns ~ 10s
Window Trigger
Source
CH1~CH2
Pattern Trigger
Pattern
0: Lower level; 1: High level; X: Ignore; : Rise; : Fall; : Rise or fall.
Level
CH1~CH2
Interval Trigger
Slope
Rising, Falling
Condition
<, >, !=, =
Source
CH1~CH2
