Hantek DSO2000 Series User Manual

69 / 72
Source (SDA/SCL)
CH1~CH2
Data format
Hex
Data Index
0~3
Condition
Start Bit, Stop Bit, No Ack, Address, Restart, Addresss and Data
Inputs
Number of channels
2 analog channels
Input Coupling
DC, AC or GND
Input Impedance, DC coupled
20pF±3pF, 1MΩ±2%
Probe Attenuation
1X, 10X
Supported Probe Attenuation Factors
1X, 10X, 100X, 1000X
Overvoltage Category
300V CAT II
Maximum Input Voltage
300V
RMS
(10X)
Isolation between channels
>40dB
Delay deviation between channels
<500ps
Measurements
Cursors
Voltage difference between cursors: △V
Time difference between cursors: △T
Reciprocal of △T in Hertz (1/ΔT)
Automatic Measurements
PkPk, Frequency, Average, Max, Min, Period, Vtop, Vmid, Vbase, Vamp, RMS, R-Overshoot,
PeriodRms, F-Preshoot, PeriodRms, PeriodAvg, RiseTime, FallTime, + Width, - Width, + Duty,
- Duty, FRR, FFF, F-Overshoot, R-preshoot, BWidth, FRF, FFR, LRR, LRF, LFR and LFF
DVM
Data Source
CH1~CH2
Measurement Type
DC RMS, AC RMS, DC
Frequency Meter
Hardware 6 bits
Math operation
Source
CH1~CH2
Operator
+, -, x, /, FFT
FFT
Point
1024
Window
Rectangle, Hanning, Hamming, Blackman, Bartlett, Flattop
Display
Show only or show all
Vertical scale
dB, VRms
Storage
Save/recall (non-volatile)
9 types of files can be saved and recalled internally, including settings, waveforms, and
references
Save to external memory
CSV file, BMP picture (24 bit)
Arbitrary Wave Generator
Number of channels
1
Standard waveforms
Sine, square, ramp, exponential, noise, DC
