70 / 72
Sine
Frequency Range
0.1Hz~25MHz
Square
Frequency Range
0.1Hz~10MHz
Duty
1%~99%
Ramp
Frequency Range
0.1Hz~1MHz
Symmetry
0%~100%
Exponential
Frequency Range
0.1Hz~5MHz
Noise
Bandwidth
25MHz
DC
Offset
1.75V(50Ω), 3.5V(High resistance)
Arbitrary wave
Frequency Range
1uHz~25MHz
Wave length
4096
Support PC download and external memory recall
Output impedance
50 Ω+1%, high impedance
Amplitude
5mV~3.5Vpp(50Ω)
10mV~7Vpp (High impedance)
Amplitude accuracy
±3dB
Frequency Resolution
1uHz
Waveform Depth
4KSa
Frequency accuracy
<10KHz,100ppm
>10KHz,50ppm
Modulation
FM
Modulation waveform
Sine, square, ramp
Modulation frequency
1Hz~50KHz
Modulation deviation
0.1Hz~ Carrier frequency
AM
Modulation waveform
Sine, square, ramp
Modulation frequency
1Hz~50KHz
Modulation depth
0%-120%
Burst
Types of
N Cycle, Infinite
Number of cycles
1~1024
Trigger source
Manual
Trigger input signal source
Level
CMOS
Probe compensator output
Output Voltage, typical
5V
Frequency, typical
1kHz±1%
General Specifications
Display
Display Type
7 inchs TFT (diagonal liquid crystal)
Display Resolution
800 (horizontal) * 480 (vertical) pixels
Display type
Point, vector
Waveform brightness
Adjustable
Grid type
Optional
Grid brightness
Adjustable
Screen brightness
Adjustable
