10
the parameter value, the right and up direction key will increase the parameter
value; it is also used for the digital selection of the virtual keyboard.
F1/F2/F3/F4: Multi-function key, in each menu mode, is responsible for selecting
corresponding menu items in the screen.
In scope, stop or run the waveform acquisition;
In DMM, hold the measuring data or update data;
In generator, turn on or off the waveform output.
Connectors
Automatically set
Auto set is one of the advantages digital oscilloscopes have. When you push the Auto
button, the oscilloscope will identify the type of waveform (sine or square wave) and adjust
CH1/CH2：Measured Signal Input
Gen Out: Waveform Generator Output
Charging and
USB Communication
Connector
