Vehicle Diagnosis
Turn on the oscilloscope, select “Vehicle Diagnosis” and press the right key to enter the
automotive test menu.
Or press the Menu button, select “Vehicle Diagnosis” and press the right key to enter the
automotive test menu.
The cursor is moved by using the upper and lower direction keys, use the left key to return
to the previous level, and use the right key to enter the next level.
Test items and recommended accessories, as shown in the table below.
Test Items
CH1
CH2
Ignition
Primary
Primary Ignition
HT201、HT30B、
HT307、HT18A
Primary Ignition (I)
CC-65(1mV/10mA)
Primary Ignition (V&I)
HT201、HT30B、
HT307、HT18A
CC-65(1mV/10mA)
Primary Ignition &
Crankshaft Sensor
HT201、HT30B、
HT307、HT18A
HT30B、HT307、
HT18A
Primary Ignition &
Secondary Ignition
HT201、HT30B、
HT307、HT18A
HT25、HT308
Secondary
Secondary Distributor
(Plug Lead)
HT25、HT308
Secondary Distributor
(King Lead)
HT25、HT308
Secondary Distributor
(Positive-fired)
HT25、HT308
Secondary Distributor
(Negative-fired)
HT25、HT308
Secondary Coil Output
Diagnosis
HT25、HT308
Primary Ignition &
Secondary Ignition
HT201、HT30B、
HT307、HT18A
HT25、HT308
Amplifier Earth
HT30B、HT307、
HT18A
Sensors
Air flow
Meter
Air flow Meter ( Hot Wire)
HT30B、HT307、HT18A
Air flow Meter (Air Vane)
Air flow Sensor (Bosch
Diesel)
Air Pressure Sensor (Diesel)
Camshaft
Camshaft (Inductive)
Camshaft (AC Excited)
Camshaft (Bosch Common
Diesel)
