User Manual
91
Rate
2mHz~1MHz
QPSK
Carrier
Waveforms
Sine, Square, Ramp, Pluse
, Harmonics, Arb. (except DC)
Source
Internal
Data Source
PN15 code, PN21 code
Rate
2mHz~1MHz
3FSK
Carrier
Waveforms
Sine, Square, Ramp, Pluse
, Harmonics, Arb. (except DC)
Source
Internal
Modulating
Waveforms
Square
Rate
2mHz~1MHz
4FSK
Carrier
Waveforms
Sine, Square, Ramp, Pluse
, Harmonics, Arb. (except DC)
Source
Internal
Modulating
Waveforms
Square
Rate
2mHz~1MHz
OSK
Carrier
Waveforms
Sine
Source
Internal, External
OscTime
8ns~4.99975ms
Rate
2mHz~1MHz
PWM
Carrier
Waveforms
Square
Source
Internal, External, another
channel
Modulating
Waveforms
Sine, Square, Ramp, Noise,
Arb
Rate
2mHz~50KHz
Width Deviation
0%
to
50%
[Sync/Mod/Trig] Input
Maximum Input
Range
75mVRMS to ±
2.5Vac+dc
Input Bandwidth
10MHz
Input
1KΩ
96
