User Manual 92
Impedance
Sweep Characteristics
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonics, Arb. (except DC)
Type
linear
TypeDirection
Up
Sweep time
1ms to 50Ks
Hold/Return
time
1ms to 50Ks
Trigger Source
Internal, External, Manual
Mark
Falling Edge of Sync signal(programmable)
Burst Characteristic
Carrier
Waveforms
Sine, Square, Ramp, Pluse, Harmonics, Arb. (except DC)
Carrier
Frequency
2mHz to 100MHz
2mHz to 80MHz
2mHz to 60MHz
2mHz to 30MHz
Burst Count
1 to 2000 000 000
Start/Stop
Phase
0° to 360°
Internal Period
2μs to 500s
Gated Source
External trigger
Trigger Source
Internal, External or Manual
Counter
Function
Frequency, Period, Positive/Negative Pulse Width, Duty Cycle
Frequency
Resolution
7 digits/second (Gate Time =1s)
Frequency
1uHz~100MHz
Gate time
10ms~16s
Voltage Range and Sensitivity
DC Coupling
DC Offset Range
±1.5VDC
1μHz to 100MHz
50mVRMS to ±2.5Vac+dc
Pulse Width and Duty Cycle Measurement
Frequency/Ampli
tude Range
1μHz to 25MHz
50mVRMS to ±2.5Vac+dc
Pulse Width
Resolution
8ns
Duty Cycle
Range (Display)
0% to 100%
