Harbor Breeze TILGHMAN - Page 14

1 4
Lowes.com/harborbreeze
FINAL INSTALLATION
3 . P l ace t he bl ad e arm ( H ) on t o t he t op of bl ad e ( F ) , t hen
t he bl ad e med al l i on ( J ) on t he bot t om. S ecu re t he
assembl y t og et her wi t h bl ad e screws ( I I ) . R ep eat f or
t he remai n i n g bl ad es ( F ) .
Hardware Used
II
B l ad e S crew x 1 5
4 . A l i g n t he hol es of on e bl ad e arm ( H ) wi t h t wo hol es
on t he mot or assembl y ( E ) an d at t ach wi t h t wo mot or
screws ( A A ) . S ecu rel y t i g ht en t he mot or screws ( A A )
wi t h a P hi l l i p s screwd ri ve r. R ep eat t hi s st ep f or t he
remai n i n g bl ad e arms ( H ) .
Hardware Used
AA
M ot or S crew x 1 0
5 . A t t ach t he p u l l chai n ext en si on ( C C ) or cu st om p u l l
chai n ext en si on ( n ot i n cl u d ed ) t o t he f an p u l l chai n .
Hardware Used
CC
P u l l C hai n
E xt en si on
x 1
H
F
J
II
E
H
AA
CC
H
a
r
b
o
r
B
r
e
e
z
e
3
4
5
