INITIAL INSTALLATION
1 . T u rn of f t he ci rcu i t breake rs an d t he wal l swi t ch t o t he
f an su p p l y l i n e l ead s.
DANGER: F ai l u re t o d i scon n ect t he p ower
su p p l y p ri or t o i n st al l at i on may resu l t i n seri ou s i n j u ry
or d eat h.
1
2 . D et ermi n e t he mou n t i n g met hod t o u se.
Helpful Hint: D own rod mou n t i n g i s best su i t ed f or
cei l i n g s 8 f t . or hi g her. F or t al l er cei l i n g s yo u may
wan t t o u se a l on g er d own rod ( n ot i n cl u d ed ) . A n g l e
mou n t i n g i s best su i t ed f or an g l ed or va u l t ed cei l i n g s.
A l on g er d own rod i s somet i mes n ecessary t o en su re
p rop er bl ad e cl earan ce.
Note: F l u shmou n t i n st al l at i on i s n ot ava i l abl e f or t hi s
i t em.
Important: I f u si n g t he an g l e mou n t , check t o en su re
t he cei l i n g an g l e i s n ot st eep er t han 2 3 ° .
2
Downrod Mounting
Flushmount Closemount
Angle Mounting
3 . E n su re t he bl ad es ( F ) wi l l be at l east 3 0 i n . f rom
an y obst ru ct i on s. A l so check t he d own rod ( A )
l en g t h t o en su re t he bl ad es ( F ) wi l l be at l east 7 f t .
abovetheoor.
A
F
3
7 ft. Min.
30 in. Min.
