INITIAL INSTALLATION
4 . R emov e t he t wo mou n t i n g brack et screws ( H H )
f rom t he rou n d hol es of can op y ( B ) . S et asi d e
f or l at er u se. D et ach mou n t i n g brack et ( C ) f rom
can op y ( B ) , t hen at t ach mou n t i n g brack et ( C ) t o
ou t l et box ( n ot i n cl u d ed ) u si n g screws an d washers
p rov i d ed wi t h t he ou t l et box .
Note: I t i s ve ry i mp ort an t yo u u se t he p rop er
hard ware when i n st al l i n g t he mou n t i n g bracke t
( C ) as t hi s wi l l su p p ort t he f an .
Important:î I f u si n g t he an g l e mou n t , en su re t he op en
en d of t he mou n t i n g brack et ( C ) i s i n st al l ed
f aci n g t he hi g her p oi n t of t he cei l i n g .
Hardware Used
HH
M ou n t i n g
B racke t S crew
x 1 0
C
B
HH
C
5 . R emove t he mot or screws ( A A ) f rom t he u n d ersi d e of
t he mot or assembl y ( E ) .
Note: I f t here are p l ast i c mot or bl ocks i n st al l ed wi t h
t he mot or screws ( A A ) , d i scard t hem bu t ke ep
t he mot or screws ( A A ) .
Hardware Used
AA
M ot or S crew x 1 0
E
AA
5
Motor Block
To Next Page
