3 - Description
50
RinseTank
One or two RinseTanks are side of the sprayer next to the MainTank. The
tanks are made of impact-proof and chemical resistant polyethylene. It
is used for rinsing and flushing of the MainTank and liquid system.
Capacity: approximately 2 x 80 litres.
CleanWaterTank
The water in this tank is for hand washing, for cleaning of clogged
nozzles etc. Only fill this tank with clean water from the tap.
The CleanWaterTank is placed on the sprayer’s left side, right behind the
manifold valves.
Capacity: approximately 15 litres.
Filters
Filters on your sprayer are there to protect components and prevent
nozzle clogging.
• A suction filter is fitted at the top of the tank. It is indicated with a
red hose tail.
• InLine filters (pressure) (A) are fitted for each boom section. InLine
pressure filters are optional on some versionsboom wings.
• Nozzle filters are fitted at each nozzle.
• A coarse filter is located below the top cover for the MainTank.
μ
ATTENTION! All the filters should be in use and their functionality must be checked regularly. Pay attention to the
correct combination of filter and mesh size. For more information, see the chapter “Technical Specifications” in this
book.
μ
ATTENTION! Always operate your sprayer with cleaned filters to ensure proper functions and to protect the interior of
the pump and valves.
