5 - Operation
87
5. Close the remaining valves.
μ
ATTENTION! For increased suction from the TurboFiller the agitation valve can be kept closed.
μ
ATTENTION! If filling water from an external tank, this can be continued while doing the next steps.
6. valveEngage the pump and set PTO speed at max. 540 RPM.
7. Open the TurboFiller lid. Open the TurboDeflector valve and the TurboFiller suction valve.
8. Measure the correct amount of powdered chemical and sprinkle it into the hopper as fast as the transfer device can
flush it down. The TurboFiller suction valve must be open for at least 20 seconds after the chemical is no longer visible
in the hopper in order to completely empty the transfer hoses into the MainTank.
€
DANGER! If the TurboFiller and the transfer hoses are not completely emptied, there is a risk of chemicals flowing back
into the hopper!
€
DANGER! Always wear face shield and other appropriate personal safety equipment, when filling chemicals.
9. If the chemical container is empty, it can be rinsed by the “chemical container cleaning device”. Place the container
over the multi-hole nozzle and push the upper lever to the left of the TurboFiller.
€
DANGER! In order to avoid spray liquid hitting the operator, do not press the lever unless the multi-hole nozzle is
covered by a container, as spray liquid may otherwise hit the operator!
μ
ATTENTION! The rinsing device uses spray liquid to rinse containers for concentrated chemicals. Always rinse the
chemical containers with clean water several times, until they are clean before disposal.
10. Flush the TurboFiller with clean water by shifting to suction from the RinseTank or from an external tank. The TurboFiller
suction valve must be open for at least 20 seconds after the rinse water is no longer visible in the hopper, in order to
completely empty the transfer hoses into the MainTank.
μ
ATTENTION! If the suction valve is not shifted to suction from a clean water supply, the hopper rinsing device uses
spray liquid for rinsing the hopper! Cleaning the TurboFiller must always be done, when the spray job is ended, and
together with cleaning the entire sprayer. A cleaning after the last filling, and before spraying, does not ensure a clean
TurboFiller!
11. Close the TurboFiller suction valve, when the hopper has been rinsed. Close the lid.
12. If closed, turn the agitation valve towards “agitation”.
13. When the spray liquid is well agitated, turn the handle for pressure
valve towards “spraying” position. The agitation continues during
spraying of the crop.
μ
ATTENTION! If foaming is a problem, turn down the agitation.
