39 P17/TI50/TO05 DSP_ABOOT O Ouput for DSP Auto boot
40 P16/TOH1/INTP5 DSP_INTREQ I Interrupt signal output to DSP
41 P15/TOH0 DIR_PDN O Output for DIR power down
42 P14/RXD6 RxD I Input for flash upgrade
43 P13/TXD6 TxD O Output for flash upgrade
44 P12/SO10 Front B RLY O Output for SPK B ON/OFF
45 P11/SI10/RXD0 24C08_SCLK O Clock signal output for 24C08
46 P10/SCK10/TXD0 24C08_SDA I/O Input & output for 24C08 control data
47 AVREF AVREF 3V3
48 AVSS AVSS GROUND
49 P27/ANI7 KEY2 I Input for KEY2 scan
50 P26/ANI6 KEY3 I Input for KEY3 scan
51 P25/ANI5 KEY1 I Input for KEY1 scan
52 P24/ANI4 BT/THERMAL_DET I BLUETOOTH DETECT
53 P23/ANI3 HDMI_HPD O Ouput for HDMI HPD(NOT USED)
54 P22/ANI2 HDMI_S2 O Ouput for HDMI S2 CONTROL(NOT USED)
55 P21/ANI1 HDMI_S2 O Ouput for HDMI S1 CONTROL(NOT USED)
56 P20/ANI0 FUNC_DN I Input for function encoder down
57 P130 ST/BY_LED O Ouput for standby led
58 P04/SCK11 ST/BY_RLY O Onput for standby relay
59 P03/S111 FUNC_UP I Input for function encoder up
60 P02/S011 FLT/PLL_DATA O Output for FLT/PLL control data
61 P01/TI010/TO00 FLT/PLL_CLK O Clock signal output for FLT/PLL
62 P00/TI000 RMC I Input for remocon data
63 P141/BUZ/INTP7 FLT_CE O Chip select output for FLT
64 P140/PCL/INTP6 POWER_DOWN I Input for power down
No. Pin Name Pin Symbol I/O Pin Description
37 P53 DSP_RDY I Input for DSP enable
38 P30/INTP1 DSP_CE O Chip select output for NJW1153
