Harman Kardon AVR 134 Service Manual

3. Terminal Functions
Table, the Terminal Functions table, identifies the external signal names, the associated pin/ball
numbers along with the mechanical package designator, the pin type(I,O, IO,OZ, or PWR), whetherthe
pin/ball has any internal pullup/pulldown resistors, whether the pin/ball is configurable as an IO in GPIO
mode, and a functional pin description.
Table.Terminal Functions
PIN
SIGNAL NAME TYPE
(1)
PULL
(2)
GPIO
(3)
DESCRIPTION
NO.
External Memory Interface (EMIF) Address and
Control
EM_A[0] 91 O-N
EM_A[1] 89 O-N
EM_A[2] 88 O-N
EM_A[3] 86 O-N
EM_A[4] 84 O-N
EM_A[5] 83 O-N
EMIF AddressBus
EM_A[6] 80 O-N
EM_A[7] 79 O-N
EM_A[8] 76 O-N
EM_A[9] 75 O-N
EM_A[10] 93 O-N
EM_A[11] 74 O-N
EM_BA[0] 96 O-N
SDRAM Bank Address and AsynchronousMemory
Low-OrderAddress
EM_BA[1] 94 O-N
EM_CS[0]
97 O-NSDRAM Chip Select
EM_CS[2]
100 O-NAsynchronous Memory Chip Select
EM_CAS
37 O-NSDRAM Column Address Strobe
EM_RAS
98 O-NSDRAM Row Address Strobe
EM_WE
38 O-NSDRAM Write Enable
EM_CKE 71 O-NSDRAM Clock Enable
EM_CLK 70 O-NSDRAM Clock
EM_WE_DQM[0]
39 O-NWriteEnableor Byte Enable for EM_D[7:0]
EM_WE_DQM[1]
67 O-NWriteEnableor Byte Enable for EM_D[15:8]
EM_OE
104 O-NSDRAM Output Enable
EM_RW
102 O-NAsynchronous Memory Read/not Write
External Memory Interface (EMIF) Data Bus
EM_D[0] 52 IO -N
EM_D[1] 51 IO -N
EM_D[2] 49 IO -N
EM_D[3] 48 IO -N
EM_D[4] 46 IO -N
EM_D[5] 45 IO -N
EM_D[6] 43 IO -N
EM_D[7] 41 IO -N
EMIF DataBus [Lower16 Bits]
EM_D[8] 66 IO -N
EM_D[9] 64 IO -N
EM_D[10] 63 IO -N
EM_D[11] 61 IO -N
EM_D[12] 59 IO -N
EM_D[13] 58 IO -N
EM_D[14] 56 IO -N
EM_D[15] 55 IO -N
15
