PIN
SIGNALNAME TYPE
(1)
PULL
(2)
GPIO
(3)
DESCRIPTION
NO.
McASP0, McASP1, McASP2, and SPI1 Serial Ports
AHCLKR0/AHCLKR1 143 IO -YMcASP0 and McASP1 ReceiveMasterClock
ACLKR0 139 IO -YMcASP0 ReceiveBit Clock
AFSR0 141 IO -YMcASP0 ReceiveFrameSync(L/RClock)
AHCLKX0/AHCLKX2 2 IO -YMcASP0 and McASP2 Transmit MasterClock
ACLKX0 142 IO -YMcASP0 Transmit Bit Clock
AFSX0 144 IO -YMcASP0 TransmitFrame Sync(L/RClock)
AMUTE0 3O - YMcASP0 MUTE Output
AXR0[0] 113 IO -YMcASP0 SerialData0
AXR0[1] 115 IO -YMcASP0 SerialData1
AXR0[2] 116 IO -YMcASP0 SerialData2
AXR0[3] 117 IO -YMcASP0 SerialData3
AXR0[4] 119 IO -YMcASP0 SerialData4
AXR0[5]/ SPI1_SCS
120 IO -YMcASP0 SerialData5 or SPI1 SlaveChipSelect
AXR0[6]/SPI1_ENA
121 IO -YMcASP0 SerialData6 or SPI1 Enable(Ready)
AXR0[7]/SPI1_CLK 122 IO -YMcASP0 SerialData7 or SPI1 SerialClock
AXR0[8]/AXR1[5]/ McASP0 SerialData8 or McASP1 SerialData5 or
126 IO -Y
SPI1_SOMI
SPI1 DataPin SlaveOutMasterIn
AXR0[9]/AXR1[4]/ McASP0 SerialData9 or McASP1 SerialData4 or
127 IO -Y
SPI1_SIMO
SPI1 DataPin SlaveInMasterOut
AXR0[10]/AXR1[3] 130 IO -YMcASP0 SerialData10 or McASP1 SerialData3
AXR0[11]/AXR1[2] 131 IO -YMcASP0 SerialData11 or McASP1 SerialData2
AXR0[12]/AXR1[1] 134 IO -YMcASP0 SerialData12 or McASP1 SerialData1
AXR0[13]/AXR1[0] 135 IO -YMcASP0 SerialData13 or McASP1 SerialData0
AXR0[14]/AXR2[1] 137 IO -YMcASP0 SerialData14 or McASP2 SerialData1
AXR0[15]/AXR2[0] 138 IO -YMcASP0 SerialData15 or McASP2 SerialData0
ACLKR1 9 IO -YMcASP1 ReceiveBit Clock
AFSR1 12 IO -YMcASP1 ReceiveFrameSync(L/RClock)
AHCLKX1 5 IO -YMcASP1 Transmit Master Clock
ACLKX1 7 IO -YMcASP1 Transmit Bit Clock
AFSX1 11 IO -YMcASP1 Transmit Frame Sync (L/RClock)
AMUTE1 4O - YMcASP1 MUTE Output
SPI0, I2C0, and I2C1 Serial Port Pins
SPI0_SOMI/I2C0_SDA 111 IO -Y
SPI0 DataPin SlaveOutMasterInor I2C0SerialData
SPI0_SIMO 110 IO -YSPI0 DataPin SlaveInMasterOut
SPI0_CLK/I2C0_SCL 108 IO -YSPI0 SerialClockor I2C0SerialClock
SPI0_SCS/I2C1_SCL
107 IO -YSPI0 SlaveChipSelector I2C1SerialClock
SPI0_ENA/I2C1_SDA
105 IO -YSPI0 Enable(Ready)or I2C1SerialData
Clocks
OSCIN 23 I-N1.2-VOscillatorInput
OSCOUT 24 O-N1.2-VOscillatorOutput
OSCV
DD
25 PWR -NOscillator1.2-VV
DD
tappoint(forfilteronly)
OSCV
SS
22 PWR -NOscillatorV
SS
tappoint(forfilteronly)
CLKIN 17 I-NAlternate clock input (3.3-V LVCMOS Input)
PLLHV 27 PWR -NPLL 3.3-VSupplyInput(requiresexternalfilter)
DeviceReset
RESET
14 I-NDeviceresetpin
16
