Harman Kardon AVR 134 Service Manual

Parts without Parts No. are not supplied.
Parts without version mentioned are common ones.
Q'TY VER. Q'TY VER. Q'TY VER.
32 SW,ENCODER 1 G121123070020S
INSTRUCTION MANUAL 1 5707000001980S 33 TER,RCA 3PIN 1 G606040320020S Q204C KTC3964, NPN 1 J502396400010S
BOX,GIFT 1 6007211180080S 34 SHIELD 1 3070210466000S Q204FL KTC3964, NPN 1 J502396400010S
CUSHION,SNOW 2 6230212064000S 35 PCB GUIDE 3 1 7028066834010 Q204FR KTC3964, NPN 1 J502396400010S
CLIP 4 6250040020010S 36 PCB GUIDE 2 1 7028066833010 Q204SL KTC3964, NPN 1 J502396400010S
PE,SHEET 1 6327040059000S 37 FOOT 2 4007040201060S Q204SR KTC3964, NPN 1 J502396400010S
POLY BAG 1 6337040062010S 38 PCB MAIN 1 7028066831010 Q205C KTD1510, NPN 1 J503151000020S
POLY BAG 1 6337210242000S 39 HEAT SINK 1 2120043538030S Q205FL KTD1510, NPN 1 J503151000020S
REMOCON 1 8300310000020S 40 HEAT SINK 1 2120044298010S Q205FR KTD1510, NPN 1 J503151000020S
ANTENNA,LOOP 1 E601016000010S 41 PCB DSP 1 702
5HK0814013 corr Q205SL KTD1510, NPN 1 J503151000020S
ANTENNA,WIRE(FM) 1 E605010070001S 42 MODULE OPTICAL 1 E100116500040S Q205SR KTD1510, NPN 1 J503151000020S
BATTERY,DRY 3 G670001R50210S 43 TER,RCA 2PIN 1 G601206A0200YS Q206C KTB2510, PNP 1 J501251000010S
CORD ASSY 1 L068250160020S 44 SHIELD PLATE DSP 1 3070210476000S Q206FL KTB2510, PNP 1 J501251000010S
CASING ASSY 1 1018HK0814010 45 TER,RCA 12PIN 1 G6081201A120YS Q206FR KTB2510, PNP 1 J501251000010S
46 TER,RCA 3PIN 1 G60631901B20YS Q206SL KTB2510, PNP 1 J501251000010S
1 WINDOW 1 5077212543010S 47 TER,RCA 6PIN 1 G603610A0041YS Q206SR KTB2510, PNP 1 J501251000010S
2FILTER 15200210262000S 48TUNER,FM/AM 1E903004100010S
3 BADGE 1 5630210548000S 49 TER,RCA 3PIN 1 G606305A1400YS
4 PANEL FRONT 1 3067213971010S 50 TER,RCA 2PIN 1 G601207BE050YS
5 FELT 2 2690040057010S 51 TER,RCA 9PIN 1 G6070902C016YS
6 LENS 1 3710210793000S 52 PCB COMPONENT 1 7028066835010
7BUTTON 15097213641000S 53FOOT 24000040201010S
8 BUTTON 1 5097213631000S 54 TER,BOARD PUSH 8P 1 G598801SA090YS
9 P.C.B SUB ASSY (STANDBY SW) 1 7028066854010 55 TER,BOARD PUSH 6P 1 G596601SA090YS
10 BRACKET 1 4010213546000S 56 CHASSIS 1 3207212506400S
11 SW,PUSH 1 G000122006060S 57 SOCKET,POWER AC 1 G430040550010S
12 P.C.B SUB ASSY (POWER SWITCH) 1 7028066853010 58 JACK,D6.5 1 G402PJ619A01YS
13 P.C.B SUB ASSY (FRONT) 1 7028066851010 59 P.C.B SUB ASSY 1 7028066852010
14 HEAT SINK 1 2120210538100S 60 DISPLAY,FLT 1 K530080300010S
15 PCB GUIDE 1 7028066832010 61 HOLDER 1 432004078301AS
16 BRACKET 5 4010056906010S 62 POSISTOR 1 F320161020240S
17 CABINET 1 3007041236061S 63 P.C.B 1 7020067770000S
18 PCB AMP 1 7028064971010 64 SHIELD 2 3070045526010S
19 CHASSIS 1 3200200026020S
20 POWER TRANS 1 8200858630220S S1 SCREW 4 1500040083B10S
21 CUSHION 1 4050044345010S S2 SCREW,TAP TITE 2 B020030103B11S 30
22 PCB STANDBY 1 7028066901010 S2 SCREW,TAP TITE 28 B020030103B11S
23 PLATE 1 4470211422000S S3 SCREW,TAP TITE 5 B020030181B10S
24 KNOB 1 5087211781000S S4 SCREW,TAP TITE ASSY 4 B028940101B10S
25 BUSHING 1 2410210061000S S5 SCREW 15 1507041146010S
26 KNOB 1 5080211793000S S7 SCREW,TAP TITE 13 B020030081B10S
27 PLATE 1 4470211432000S S7 SCREW,TAP TITE 11 B020030081B10S
28 CN,PLUG CONTACT 1 G480040100010S S7 SCREW,TAP TITE 22 B020030081B10S
29 PCB USB 1 7028066862010 S7 SCREW,TAP TITE 3 B020030081B10S
30 SHIELD 1 3070210456000S S8 SCREW,TAP TITE 7 B020030083B10S
31 BUTTON 1 5097213651000S S9 SCREW,TAP TITE 6 B020930083B10S
PARTS NO.DESCRIPTION
SCREWS
DESCRIPTION PARTS NO.
PACKAGE
CABINET & CHASSIS
DESCRIPTION PARTS NO.
MISCELLANEOUS
Model : AVR-134
MECHANICAL PARTS LIST
