Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
FRONT/VOLUME/STANDBY PCB/VOLUME/STANDBY PCB COP12168C
R926 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R931 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R932 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R933 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R934 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R935 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R936 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R941 CRD25TJ432T RES , CARBON(1/4W, 4.3K) (1/4W, 4.3K) 1 EA
R942 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R943 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R944 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R951 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R953 CRD20TJ362T RES , CARBON 3.6K OHM 1/5W J 1 EA
R954 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
VR74 CSR2A037Z ENCODER 1EA
Miscellaneous
S311 CST1A024ZT SW , TACT 1EA
S312 CST1A024ZT SW , TACT 1EA
S313 CST1A024ZT SW , TACT 1EA
S314 CST1A024ZT SW , TACT 1EA
S315 CST1A024ZT SW , TACT 1EA
S316 CST1A024ZT SW , TACT 1EA
S317 CST1A024ZT SW , TACT 1EA
S318 CST1A024ZT SW , TACT 1EA
S319 CST1A024ZT SW , TACT 1EA
S320 CST1A024ZT SW , TACT 1EA
S321 CST1A024ZT SW , TACT 1EA
S322 CST1A024ZT SW , TACT 1EA
S323 CST1A024ZT SW , TACT 1EA
S330 CST1A024ZT SW , TACT 1EA
L151 HLQ02C100KT COIL , AXAIL (10UH) 1EA
BK71 CMD1A572 BRACKET , FIP 1EA
BK72 CMD1A572 BRACKET , FIP 1EA
BN51 CWB1C907250BM001 SHIELD WIRE ASS'Y (2.5mm, 250mm, 7pin) 1 EA
BN52 CWB1C903400BM001 SHIELD WIRE ASS'Y (2.5mm, 400mm, 3pin) 1 EA
BN61 CJP12GB143ZB PIN HEADER , DIP SOCKET(12PIN, 2.54mm, ANGLE) 1 EA
BN73 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) 1 EA
BN74 CWB1C905120BM WIRE ASS'Y 1EA
CN61 CJP12GA239ZB PIN HEADER(12P, 2.54mm), STRAIGHT TYPE 1 EA
CN71 CJP05GB03ZY WAFER , ANGLE (2.5mm) 1 EA
CN72 CJP31GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 31P) MOLEX 52045-**45 1 EA
CN73 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1 EA
CN74 CJP05GB03ZY WAFER , ANGLE (2.5mm) 1 EA
ET63 CMC2A325 PLATE , EARTH AVR155 1 EA
ET64 CMC4A111 PLATE , EARTH 1EA
FB13 KLZ9H001Z BEAD , CORE 1EA
FB14 KLZ9H001Z BEAD , CORE 1EA
FB15 KLZ9H001Z BEAD , CORE 1EA
F1 CFL162BD01GINK V.F.D 162-BD-01GINK 1 EA
JK51 CJJ9X006Z JACK , USB STRAIGHT(BLACK) U250FD004BY 1 EA
JK52 CJJ4S028Y JACK , BOARD (3P SILVER) 1 EA
JK61 CJJ4M041Y JACK , BOARD (COAX) 1 EA
JK62 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
JK63 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) 1 EA
RL91 CSL4A016ZU RELAY , 12V 2C2P BC3-12H 1 EA
CBT2A1064 KNOB , STANDBY 1EA
CBT2A1065 KNOB , BACK 1EA
CGB1A158Y BADGE , FRONT HARMAN/KARDON 1 EA
CGL1A265Y INDICATOR , POWER 1EA
CGW3A447RHZB24 PANEL , FRONT 1EA
CHR301 CLAMPER 6EA
CMC1A372 PLATE , SHIELD 2EA
CMC2A323 PLATE , SHIELD 1EA
AVR1600 harman/kardon
39
