Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
FRONT/VOLUME/STANDBY PCB/VOLUME/STANDBY PCB COP12168C
CMC2A326 PLATE , EARTH AVR1600 3 EA
CMC2A338 PLATE , EARTH AVR1600 2 EA
CMD2A443 BRACKET , SIDE 2EA
CMH1A297 HOLDER , USB 1EA
CMH2A215 HOLDER , LED AVR1600 1 EA
CMZ1A127 FILTER , FIP 1EA
CPE1A009 SHEET , BLIND 1EA
CTB3+8JFZR SCREW 28 EA
CTWS3+10GR SCREW 1EA
CB72 CWC4C4A31B250B08 CARD , CABLE (31p,1.25mm,250mm,08mm) 1 EA
MAIN PCB ASS'Y COP12170B
Capacitors
C501 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C502 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C503 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C504 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C505 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1 EA
C507 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
C508 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1 EA
C510 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
C561 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C562 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C563 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C564 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C565 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C566 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C567 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C568 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C569 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C570 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C571 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C572 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C573 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C574 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C575 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C681 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C682 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C683 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C684 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C685 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C726 CCKT1H221KB CAP , CERAMIC 220PF 50V K 1 EA
C801 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C802 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C803 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C804 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
C805 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C806 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
C811 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C812 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C813 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
