Harman Kardon AVR 1600 - Page 50

Ref. Designator Part Number Qty
Description
MAIN PCB ASS'Y COP12170B
L507 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1 EA
RY94 CSL1E002ZE RELAY , POWER G5PA-1 (DC 6V) 1 EA
TH91 KRTP42T7D330B THERMAL SENSOR , POSISTOR P42T7D330BW20 1 EA
T902 CLT5I005ZU TRANSFORMER, SUB 1EA
POWER PCB/DIGITAL IN/PROTECT PCB ASS'Y CUP12172C
Capacitors
C104 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1 EA
C105 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1 EA
C106 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J 1 EA
C107 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1 EA
C108 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1 EA
C109 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J 1 EA
C110 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C123 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z 1 EA
C124 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z 1 EA
C125 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J 1 EA
C127 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C131 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
C132 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z 1 EA
C133 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z 1 EA
C134 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z 1 EA
C135 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C136 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C750 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C752 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C911 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE 1 EA
C912 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C919 CCKT1H102KB CAP , CERAMIC 1000PF 50V K 1 EA
C920 CCEA1HH470T CAP , ELECT 47UF 50V 1 EA
C922 KCME2E104JP04T CAP , METALLIZED FILM (0.1UF/250V) (0.1UF/250V) 1 EA
C925 CCME2A103JXT CAP , METALLIZED FILM (0.01UF/100V) (0.01UF/100V) 1 EA
C926 CCME2A103JXT CAP , METALLIZED FILM (0.01UF/100V) (0.01UF/100V) 1 EA
C931 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C932 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C935 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C936 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J 1 EA
C937 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C938 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C939 CCEA1EH101T CAP , ELECT 100UF 25V 1 EA
C940 CCEA1EH101T CAP , ELECT 100UF 25V 1 EA
C129 CCEA1EH103E CAP , ELECT (10000uF/25V,22x30,KR3) KR3-025V103MM300 1 EA
C929 CCEA1VH222EZ CAP , ELECT (2200UF/35V, 12.5X31) KR3-35V222MH1-L/C4.0 1 EA
C930 CCEA1VH222EZ CAP , ELECT (2200UF/35V, 12.5X31) KR3-35V222MH1-L/C4.0 1 EA
Semiconductors
D114 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D115 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D116 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D117 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D124 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D125 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D801 CVD1SS133MT DIODE 1SS133 1 EA
D802 CVD1SS133MT DIODE 1SS133 1 EA
D104 HVDUF5404H DIODE , ULTRAFAST (DELTA) UF5404H 1 EA
D105 HVDUF5404H DIODE , ULTRAFAST (DELTA) UF5404H 1 EA
D991 CVDGBJ1006BIA DIODE HEAT SINK ASS'Y (CMY2A138) (CMY2A138) 1 EA
Q911 HVTKTA1267YT TRANSISTOR PNP KTA1267Y 1 EA
Q912 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1 EA
Q913 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1 EA
IC81 CVIKIA7905PI I.C , REGULATOR(-5V) KIA7905PI 1 EA
IC83 CVIKIA278R15PI I.C , REGULATOR(15V OUTPUT LOW DROP) KIA278R15PI 1 EA
