Ref. Designator Part Number Qty
Description
POWER PCB/DIGITAL IN/PROTECT PCB ASS'Y CUP12172C
IC84 CVIKIA7915PI I.C , REGULATOR(15V, TO-220AB) KIA7915PI 1 EA
D991 HVDGBJ1006 DIODE , BRIDGE 1EA
Resistors
R120 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R750 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R751 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R901 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
R912 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1 EA
R913 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1 EA
R917 CRD25TJ153T RES , CARBON (15K OHM) (15K OHM) 1 EA
R918 CRD25TJ153T RES , CARBON (15K OHM) (15K OHM) 1 EA
R919 CRD25TJ153T RES , CARBON (15K OHM) (15K OHM) 1 EA
R920 CRD25TJ153T RES , CARBON (15K OHM) (15K OHM) 1 EA
R925 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R927 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R928 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R942 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R104 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1 EA
R105 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1 EA
Miscellaneous
F110 KBA2D3150A2EYT FUSE(382 Series, 250V, 3.15A) 382 250V/3.15 1 EA
F111 KBA2D3150A2EYT FUSE(382 Series, 250V, 3.15A) 382 250V/3.15 1 EA
BN17 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) 1 EA
BN20 CWB1D00708058 WIRE ASS'Y (LOCKING TYPE, 2.5MM, 7PIN, 80MM) 1 EA
BN96 CWB1D00912058 WIRE ASS'Y (LOCKING TYPE, 2.5MM, 9PIN, 120MM) 1 EA
CN11 CJP08GB142ZB PIN HEADER (08P, 2.54mm) , ANGLE TYPE 1 EA
CN12 CJP08GA221ZB FEMALE HEADER (08P,2.54mm) , STRAIGHT TYPE 1 EA
CN20 CJP05GA90ZY WAFER , 5P(DIP, 3.96PITCH) 1 EA
CN82 CJP07GI237ZW LOCKING TYPE , STRAIGHT WAFER, 2.5MM 1 EA
CN96 CJP09GJ243ZW WAFER (9P LOCK ANGLE 2.5MM) 1 EA
CMY2A138 HEAT SINK 1EA
CTB3+12JR SCREW 1EA
ET01 CMD1A387 BRACKET , PCB 1EA
JK75 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
JK76 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
VIDEO IN/OUT PCB ASS'Y CUP12174C
Capacitors
C401 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C402 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C411 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C421 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C451 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C461 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C462 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C463 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C464 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C483 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C491 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C601 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C602 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C603 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C604 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C605 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C606 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C611 CCCT1H030CC CAP , CERAMIC 3PF 50V C 1 EA
C612 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C613 CCCT1H030CC CAP , CERAMIC 3PF 50V C 1 EA
C614 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
AVR1600 harman/kardon
51
