Harman Kardon AVR 1600 - Page 52

Ref. Designator Part Number Qty
Description
VIDEO IN/OUT PCB ASS'Y CUP12174C
C615 CCCT1H030CC CAP , CERAMIC 3PF 50V C 1 EA
C616 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C621 CCCT1H030CC CAP , CERAMIC 3PF 50V C 1 EA
C622 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C623 CCCT1H030CC CAP , CERAMIC 3PF 50V C 1 EA
C624 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C625 CCCT1H030CC CAP , CERAMIC 3PF 50V C 1 EA
C626 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C627 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C628 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C629 CCEA0JH102T CAP , ELECT 1000UF 6.3V 1 EA
C630 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C631 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C632 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C671 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C672 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C673 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C701 CCBS1H270JT CAP , CERAMIC(27PF/50V) CH UP025SL270J-A-B Z 1 EA
C702 CCBS1H270JT CAP , CERAMIC(27PF/50V) CH UP025SL270J-A-B Z 1 EA
C705 CCBS1H181KBT CAP , CERAMIC(180PF/50V) CH UP025 B181K-A-B Z 1 EA
C708 CCEA1HHR47T CAP , ELECT 0.47UF 50V 1 EA
C711 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C712 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C717 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C721 CCBS1H560JT CAP , CERAMIC(56PF/50V) CH UP025SL560J-A-B Z 1 EA
C722 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C723 CCEA1HH0R1T CAP , ELECT 0.1UF 50V 1 EA
C725 HCQI1H682JZT CAP , MYLAR 6800PF 50V J 1 EA
C726 CCEA1HH1R0T CAP , ELECT 1UF 50V 1 EA
C731 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z 1 EA
C732 CCBS1H330JT CAP , CERAMIC(33PF/50V) CH UP025SL330J-A-B Z 1 EA
C733 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C734 CCEA1HH1R0T CAP , ELECT 1UF 50V 1 EA
C736 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C737 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C741 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
Semiconductors
IC101 CVINJM2595MTE1 I.C , VIDEO S/W (JRC) NJM2595MTE1 1 EA
IC102 CVINJW1321FP1 I.C , VIDEO S/W (JRC) NJW1321FP1 1 EA
IC103 HVILC74763M I.C , OSD LC74763M 1 EA
IC104 HVI74ACT04M I.C , HEX (ST) INVERTER 74ACT04M 1 EA
D741 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
Q512 HVTKRC107MT TRANSISTOR NPN KRC107M 1 EA
Q712 HVTKTA1267YT TRANSISTOR PNP KTA1267Y 1 EA
Q716 HVTKTC3199YT TRANSISTOR NPN KTC3199Y 1 EA
Resistors
R401 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
R402 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R411 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R421 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R451 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R461 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R491 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R601 CRD20TJ560T RES , CARBON 56 OHM 1/5W J 1 EA
R603 CRD20TJ360T RES , CARBON (36 OHM) (36 OHM) 1 EA
R605 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
R611 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R613 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R615 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R621 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R623 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
