Ref. Designator Part Number Qty
Description
VIDEO IN/OUT PCB ASS'Y CUP12174C
R625 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R641 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R642 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
R674 CRD20TJ330T RES , CARBON 33 OHM 1/5W J 1 EA
R675 CRD20TJ330T RES , CARBON 33 OHM 1/5W J 1 EA
R676 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
R677 CRD20TJ360T RES , CARBON (36 OHM) (36 OHM) 1 EA
R678 CRD20TJ560T RES , CARBON 56 OHM 1/5W J 1 EA
R701 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R705 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R706 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R707 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R711 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R713 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R714 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1 EA
R715 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J 1 EA
R716 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R717 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1 EA
R721 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R724 CRD20TJ393T RES , CARBON (39K OHM) (39K OHM) 1 EA
R725 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R726 CRD20TJ682T RES , CARBON 6.8K OHM 1/5W J 1 EA
R727 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R728 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R735 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R737 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R742 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R743 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R744 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
Miscellaneous
L731 KLQ5R6J405T COIL, PEAKING(RADIAL) 5.6UH J 4X5 1 EA
L736 HLQ02C101JT COIL , AXAIL 100UH,J 1 EA
BN14 CJP15GA115ZY WAFER , CARD CABLE 1 EA
CN18 CJP18GB142ZB PIN HEADER (18P, 2.54mm) , ANGLE TYPE 1 EA
JK61 CJJ4S010Z JACK , BOARD 1EA
JK62 CJJ4R045Z JACK , BOARD 1EA
JK63 CJJ4N043Z JACK , BOARD 1EA
JK64 CJJ4S030Z JACK , BOARD 3P,G/B/R,SILVER 1 EA
X701 HOX14318E220C CRYSTAL (14.318MHz) 1 EA
INPUT (DSP) PCB ASS'Y CUP12176C
Capacitors
C200 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C201 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C202 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C203 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C204 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C205 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C206 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C207 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C208 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C209 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C210 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C211 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C212 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C213 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C214 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C215 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C216 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C219 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C220 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
AVR1600 harman/kardon
53
