Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y CUP12178C
R875 CRJ10DJ202T RES , CHIP (2K OHM) (2K OHM) 1 EA
R876 CRJ10DJ202T RES , CHIP (2K OHM) (2K OHM) 1 EA
R877 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R878 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R879 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R880 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R882 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R883 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
Miscellaneous
X801 COX28636E330S CRYSTAL (28.63636MHz HC-49/SMD, 33PF) 1 EA
CHG1A306 CUSHION 0.5 EA
BN15 CJP17GA193ZY WAFER, CARD CABLE (SMD) 1 EA
JK91 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK92 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK93 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK94 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
L801 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
L802 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
L803 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
L804 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
L805 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L806 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L807 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L808 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L809 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L810 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L811 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L812 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L813 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L814 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L815 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
BN54 CJP18GB143ZB FEMALE HEADER (18P, 2.54mm) , ANGLE TYPE 1 EA
BN82 CWB1D00715058 WIRE ASS'Y (LOCKING TYPE, 2.5MM, 7PIN, 150MM) 1 EA
DC DC PCB ASS'Y COP12167B
C50 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C51 CCEC1ACEEX151TY CAP , ELEC SMD (150uF/10V, 8X10.5, SANYO) 10CE150EX 1 EA
C52 CCEC1CRV471T CAP , SMD ELECT(MANLEX RV, 16V/470, 10X10) 16V/470 1 EA
C53 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C54 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C55 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C56 CCEC1EHVH151TY CAP , ELEC SMD (150uF/25V, 8X10.5, SANYO) 25HVH150M 1 EA
C57 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C58 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
D50 CVDSS34SR DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA SS34SR 1 EA
IC50 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN SI8005QTL 1 EA
R50 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
R51 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) (62K OHM) 1 EA
R52 CRJ10DJ512T RES , CHIP (5.1K OHM) 1608 SIZE 1 EA
R53 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R54 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
L50 CLQ13E470MRZ COIL , SMD POWER (47UH/3A) CMI-SSP12L80F-SERIES 1 EA
L51 CLQ13E220MRZ COIL , SMD POWER (22UH/3A) CMI-SSP12L80F-SERIES 1 EA
BK51 CMD1A569 BRACKET , PCB 1EA
CN50 CJP08GB142ZB PIN HEADER (08P, 2.54mm) , ANGLE TYPE 1 EA
BOTTOM CHASSIS ASS'Y
CHD1A012ZR SCREW , SPECIAL 2EA
CHD1A023R SCREW , SPECIAL 4EA
CHD4A012R SCREW , SPECIAL 5EA
AVR1600 harman/kardon
68
