Harman Kardon AVR 1600

Ref. Designator Part Number Qty
Description
BOTTOM CHASSIS ASS'Y
CB12 CWC4C4A27B100B10 CARD , CABLE (27p,1.25mm Pitch,100mm Length,Protec 1 EA
CB14 CWC4C4A15B080B10 CABLE , CARD (15P,1.25MM,80MM,B,10MM) 1 EA
CB15 CWC4F2A17A100B10 CARD , CABLE (17P,1.0mm Pitch,100mm Length,Protect 1 EA
F901 KBA2C6300TLEY FUSE(218 Series, 250V, 6.3A) 1 EA
T901 CLT5U035ZU TRANS , POWER 1EA
CHE170 HOLDER , PCB 2EA
CHE36-3 CLAMPER , WIRE 1EA
CHG1A113 RUBBER 3EA
CHG1A160Z CUSHION , RUBBER 1EA
CHG1A373 CUSHION , FOOT AVR1600 4 EA
CJA523FBXA CORD , POWER CRX-E320/U(1.8M, FERRITE) NISPT-2 18AWG/2C 105C BK 1 EA
CJA523FBYA CORD , POWER 1EA
CKF1A398Y PANEL , REAR 1EA
CKF1A398Z PANEL , REAR 1EA
CKL1A094 FOOT , A AVR1600 2EA
CKL1A095 FOOT , B AVR1600 2EA
CTB3+10JFZR SCREW 18 EA
CTB3+6FFZR SCREW 8EA
CTB3+8JFZR SCREW 10 EA
CTS3+8JFZR SCREW 4EA
CTW3+12JR SCREW 2EA
CUA2A294 CHASSIS , BOTTOM 1EA
KHR1A028 BUSHING , AC CORD 1EA
BN90 CSH1A009ZVB SWITCH , MOMS WIRE ASS'Y (2P, 80MM, RED) 1 EA
CSH1A009ZV SWITCH , MOMS 1EA
CWB4F202080UK WIRE ASS'Y (3.96MM, 80MM, 2P, RED) 1 EA
TUN1 CNVMW004MV1S63S
A
TUNER(USA) FM(SCREW : F TYPE), AM(S/LAB) KST-MW004MV1-S63SA 1 EA
