Preliminary Information ADV7604
Pr. 0 | Page 11 of 12
connector. Result available via I
2
C. This signal can be buffered and output
to the FBOUT pin. VS on Graphics Port 2. The VS input signal is used in CP
mode for 5-wire timing mode. VS_IN2 is a 3.3 V input that is 5 V tolerant.
15M TRI5 Misc Analog Trilevel/bilevel input on the SCART or D-terminal connector. Result
available via I
2
C. This signal can be buffered and output to the FBOUT pin.
15N TRI3 Misc Analog Trilevel/bilevel input on the SCART or D-terminal connector. Result
available via I
2
C. This signal can be buffered and output to the FBOUT pin.
15P AVDD Power Analog supply voltage (1.8V)
15R Y_MUX_OUT Misc Analog Buffered output of the Y channel.
15T TRI1 Misc Analog Trilevel/bilevel input on the SCART or D-terminal connector. Result
available via I
2
C. This signal can be buffered and output to the FBOUT pin.
15U SYNC1 Misc Analog This is a synchronization on green or luma input (SOG/SOY) used in
embedded synchronization mode. User configurable.
15V AIN1 Analog Video Input Analog video input channel
16A TVDD Power Terminator supply voltage (3.3V)
16B TVDD Power Terminator supply voltage (3.3V)
16C DGND Ground Ground
16D TVDD Power Terminator supply voltage (3.3V)
16E DGND Ground Ground
16F CVDD Power Comparator supply voltage (1.8V)
16H AVDD Power Analog supply voltage (1.8V)
16J AVDD Power Analog supply voltage (1.8V)
16K AVDD Power Analog supply voltage (1.8V)
16L TRI7/HS_IN2 Misc Analog Dual purpose pin. Trilevel/bilevel input on the SCART or D-terminal
connector. Result available via I
2
C. This signal can be buffered and output
to the FBOUT pin. HS on Graphics Port 2. The HS input signal is used in CP
mode for 5-wire timing mode. HS_IN2 is a 3.3 V input that is 5 V tolerant.
16M TRI6 Misc Analog Trilevel/bilevel input on the SCART or D-terminal connector. Result
available via I
2
C. This signal can be buffered and output to the FBOUT pin.
16N TRI4 Misc Analog Trilevel/bilevel input on the SCART or D-terminal connector. Result
available via I
2
C. This signal can be buffered and output to the FBOUT pin.
16P AVDD Power Analog supply voltage (1.8V)
16R TRI2 Misc Analog Trilevel/bilevel input on the SCART or D-terminal connector. Result
available via I
2
C. This signal can be buffered and output to the FBOUT pin.
16T SYNC2 Misc Analog This is a synchronization on green or luma input (SOG/SOY) used in
embedded synchronization mode. User configurable.
16U AVDD Power Analog supply voltage (1.8V)
16V AIN2 Analog Video Input Analog video input channel
17A TVDD Power Terminator supply voltage (3.3V)
17B RXA_2+ HDMI Input Digital Input Channel 2 complement of Port A in the HDMI interface.
17C RXA_1+ HDMI Input Digital Input Channel 1 complement of Port A in the HDMI interface.
17D RXA_0+ HDMI Input Digital Input Channel 0 complement of Port A in the HDMI interface.
17E
RXA_C+ HDMI Input Digital input clock complement of Port A in the HDMI interface.
17F TVDD Power Terminator supply voltage (3.3V)
17G TEST1 Test Do not connect
17H REFN Misc Analog Internal voltage reference output.
17J AGND Ground Ground
17K AIN11 Analog Video Input Analog video input channel
17L SYNC4 Misc Analog This is a synchronization on green or luma input (SOG/SOY) used in
embedded synchronization mode. User configurable.
17M AGND Ground Ground
17N AIN8 Analog Video Input Analog video input channel
17P SYNC3 Misc Analog This is a synchronization on green or luma input (SOG/SOY) used in
embedded synchronization mode. User configurable.
17R AGND Ground Ground
17T AIN5 Analog Video Input Analog video input channel
17U AVDD Power Analog supply voltage (1.8V)
