ADV7604 Preliminary Information
Pr. 0 | Page 12 of 12
17V AIN3 Analog Video Input Analog video input channel
18A DGND Ground Ground
18B RXA_2- HDMI Input Digital Input Channel 2 true of Port A in the HDMI interface.
18C RXA_1- HDMI Input Digital Input Channel 1 true of Port A in the HDMI interface.
18D RXA_0- HDMI Input Digital Input Channel 0 true of Port A in the HDMI interface.
18E RXA_C- HDMI Input Digital input clock true of Port A in the HDMI interface.
18F DGND Ground Ground
18G TEST2 Test Do not connect
18H REFP Misc Analog Internal voltage reference output.
18J AGND Ground Ground
18K AIN12 Analog Video Input Analog video input channel
18L AIN10 Analog Video Input Analog video input channel
18M AGND Ground Ground
18N AIN9 Analog Video Input Analog video input channel
18P AIN7 Analog Video Input Analog video input channel
18R AGND Ground Ground
18T AIN6 Analog Video Input Analog video input channel
18U AIN4 Analog Video Input Analog video input channel
18V AGND Ground Ground
