AVR 745 TECHNICAL SPECIFICATIONS
58 TECHNICAL SPECIFICATIONS
Audio Section
Stereo Mode
Continuous Average Power (FTC)
100 Watts per channel, 20Hz–20kHz,
@ <0.07% THD, both channels driven into 8 ohms
Seven-Channel Surround Modes
Power per Individual Channel
Front L&R channels:
85 Watts per channel
@ <0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
85 Watts @ <0.07% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, L & R back) channels:
85 Watts per channel
@ <0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High-Level) 200mV/47k ohms
Signal-to-Noise Ratio (IHF-A) 100dB
Surround System Adjacent Channel Separation
Pro Logic I/II 40dB
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz –130kHz
High Instantaneous
Current Capability (HCC) ±60 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Slew Rate 40V/µsec
FM Tuner Section
Frequency Range 87.5–108.0MHz
Usable Sensitivity IHF 1.3µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo 70/68dB
Distortion Mono/Stereo 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz, 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 520–1720kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop 500µV
Distortion 1kHz, 50% Mod 0.8%
Selectivity ±10kHz, 30dB
Video Section
Television Format NTSC
Input Level/Impedance 1V p-p/75 ohms
Output Level/Impedance 1V p-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10Hz–8MHz (–3dB)
Video Frequency Response
(Component Video) 10Hz–100MHz (–3dB)
HDMI Version 1.1
General
Power Requirement AC 120V/60Hz
Power Consumption 120W at Power On, idle; 1,405W at rated power output
(7 channels driven)
Dimensions Product Shipping
Width 17-5/16 inches (440mm) 20-1/16 inches (510mm)
Height 6-1/2 inches (165mm) 10 inches (254mm)
Depth 17-1/16 inches (435mm) 22-3/16 inches (565mm)
Weight 44 lb (19.9kg) 51 lb (23.1kg)
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon, Harman International and Logic 7 are registered trademarks of
Harman International Industries, Incorporated.
and are trademarks of Harman International Industries, Incorporated.
Dolby, Pro Logic and the Double-D symbol are registered trademarks of Dolby Laboratories.
Manufactured under license from Dolby Laboratories.
DTS, DTS Surround, DTS-ES, DTS 96/24 and DTS Neo:6 are registered trademarks of DTS, Inc.
A-BUS and A-BUS/READY are registered trademarks of Leisure Tech Electronics Pty Ltd Australia.
SACD is a trademark of Sony Corporation.
iPod is a registered trademark of Apple Computer, Inc.
DLP and Texas Instruments are trademarks of Texas Instruments.
Faroudja and DCDi by Faroudja are trademarks of Genesis Microchip, Inc.
HD-DVD is a trademark of the DVD Format/Logo Licensing Corporation (DVD FLLC).
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks
of HDMI Licensing, LLC.
Microsoft, Windows and Windows Media are registered trademarks of Microsoft Corporation in
the United States and other countries.
XM-Ready is a registered trademark of XM Satellite Radio, Inc.
Supplied Accessories
The AVR 745 is supplied with the following accessory items. Please note that they are packed in different boxes, so it is important to check each individual box before reporting
missing items. If any item is missing, please contact Harman Kardon customer service at www.harmankardon.com.
• TC 30 remote control • TC 30 software CD-ROM • microphone
• Battery for the TC 30 • TC 30 installation guide • Extender rod for microphone
• USB cable for the TC 30 • ZR 10 remote control • AM loop antenna
• TC 30 charging cradle • Two AAA batteries for ZR 10 • FM wire antenna
• Charger for the TC 30 • AC power cord
Please register your product on our Web site at www.harmankardon.com. NOTE: You’ll need the serial number of your AVR. At the same time, you can choose
to be notified about our new products and/or special promotions.
