TC 30 REMOTE CONTROL FUNCTIONS
TC 30 REMOTE CONTROL FUNCTIONS 11
0 USB Connector
1 IR Emitter Window
2 Power Button
3 Activities Button
4 Devices Button
5 Help Button
6 Screen Buttons
7 LCD Screen
8 Page Left/Right Buttons
9 Transport Control Buttons
A Device Control Buttons
B Mute Button
C Volume Controls
D Navigation Buttons
E OK/Enter Button
F Glow Button
G Channel Up/Down
H Numeric Keys
I Infrared Learning Port
I
3
F
0
1
2
4
6
7
5
6
8
9
B
A
C
E
D
G
H
NOTES:
• The function names shown here are each button’s
feature when used with the AVR 745. Most
buttons have additional functions when used with
other devices.
• To make it easier to follow the instructions that refer
to this illustration, a larger copy may be downloaded
from the Product Support section for this product at
www.harmankardon.com.
