AVR745 Electrical Parts List
Ref. Designator Part Number
Description
DSP PCB ASS'Y
Capacitors
C407 C408 C409 H03-CEHEC02275E-R CE 220UF +20% 10.0V D6.3XL11 P5MM 85C SK 220/10V 5 X11
C959 H03-CEHEC0477MN-R CE 470U0F +20% 10.0V 6.3X11 85C P5MM SK 470/10V 6.3 X11
C106 C107 C116 C117 C130
C131 C140 C141 C148 C149
C162 C163 C166 C167 C176
C177 C196 C197 C277 C284
C289 C308 C316 C350 C353
C362 C365 C373 C376 C423
C424 C448 C449 C450 C451
C452 C453 C492 C495 C595
C651 C654 C902
H03-CEHFC01062S-R CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C101 C125 C153 C204 C205
C220 C221 C269 C271 C274
C357 C431 C482 C483 C484
C485 C515 C635 C682 C744
C745 C904 C912
H03-CEHFC01072S-R CE 100UF +20% 16V D6.3XL7 P2.5MM 2000hours 85C
C403 C412 C418 C436 C454
C465
H03-CEHFC01075E-R CE 100UF +-20% 16.0V D5XL11 P5MM 85C SK 100/16V 5 X11
C180 C211 C234 C238 C265
C305 C319 C514 C600 C609
C673 C687 C958
H03-CEHFC04762S-R CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C
C821 C822 H03-CEHGC01075E-R CE 100U0F +20% 25.0V 6.3X11 85C P5MM SK 100/25V 6.3 X11
C520 CEHIC01042S-R CE 100NF +20% 50V SSE TYPE D4XL7 P2.5MM 85C
C207 C208 C583 C584 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C276 H03-CEHIC0474NN-R CE 0.47UF +20% 50.0V 85C 5X11 P5MM
C304 H03-CEHIC04755E-R CE 4U7F +20% 50.0V 85C P5MM SK 4.7/50V 5 X11
C503 C628 C629 CFIOC0104NN-R CPM 100N0F +10% 250.0V
C521 H03-CEMIC04752H-R CAP ELEC 4.7UF 50V M 5X11 SHL P2.5MM
C301 C311 C312 C313 C315
C327 C328 C330 C331 C419
C420 C429 C430 C434 C435
C444 C445 C456 C457 C462
C463 C472 C473 C478 C479
C801 C802 C803 C804 C805
C806 C807 C808 C809 C810
C811 C812 C813 C814 C815
C816
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C223 CZJII0101CE-R CAP CERAMIC/CHIP 100PF 50V CH J NPO 0805
C222 CZJII0102CC-R CAP CHIP 1nF 50V X7R J 0805
C700 C702 C720 C743 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C224 C225 CZJII0270BE-R CAP CHIP 27P0F +5% -5% 50.0V NP0 0603
C263 C264 C309 C310 C632
C633
CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C326 C329 CZJII0470BE-R CAP CHIP 47P0F +5% -5% 50.0V NPO 0603
C194 C195 C198 C199 CZJII0471BE-R CCCFMIC 470P0F +5% -5% 50.0V NP0
C132 C332 C333 C425 C426
C438 C439 C466 C467 C468
C469
CZKII0102BC-R CAP CHIP 1N0F +10% -10% 50.0V X7R 0603
C701 C703 C706 C717 CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C229 C380 C382 C596 C597
C685
CZKII0122BC-R CAP CHIP 1N2F +10% -10% 50.0V X7R 0603
C104 C105 C108 C109 C114
C115 C118 C119 C128 C129
C133 C138 C139 C142 C143
CZKII0221BA-R CAP CHIP 220PF 50V K SL 0603
C652 C653 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C182 C183 C200 C201 C598
C599
CZKII0272BC-R CAP CHIP 2N7F +10% -10% 50.0V X7R 0603
C102 C103 C110 C111 C112
C113 C120 C121 C126 C127
C134 C135 C136 C137 C144
C145
CZKII0821BC-R CAP CHIP 820P0F +10% -10% 50.0V X7R 0603
AVR745
harman/kardon
