Harman Kardon AVR 745 Service Manual

Ref. Designator Part Number
Description
DSP PCB ASS'Y
C150 C154 C157 C161 C165
C168 C175 C178 C202 C206
C209 C210 C212 C213 C214
C215 C217 C218 C226 C230
C232 C233 C242 C246 C247
C248 C249 C250 C251 C252
C253 C256 C267 C268 C272
C273 C275 C278 C282 C283
C292 C303 C306 C307 C318
C320 C322 C324 C325 C340
C343 C346 C347 C348 C351
C352 C354 C355 C358 C360
C361 C363 C364 C367 C368
C371 C372 C374 C375 C378
C404 C405 C406 C411 C413
C414 C421 C422 C432 C433
C440 C441 C442 C443 C458
C459 C460 C461 C474 C475
C476 C477 C487 C490 C491
C493 C494 C497 C498 C513
C522 C525 C574 C580 C582
C589 C607 C610 C611 C634
C641 C642 C643 C644 C645
C663 C672 C674 C686 C708
C715 C824 C903 C910 C913
C918 C922 C925 C926 C927
C928 C929 C930 C946~C954
C956 C960~C978 C980 C981
C982 C983 C986 C987 C988
C989 C990 C991 C992 C931
C932
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C240 C241 CSJIE0300BG-R CAP,CHIP FORM 30P +/-5% 50V C0G 0603
C314 C486 C825 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C505 C506 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603 EUROPE ONLY
C302 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C683 C684 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C227 C228 CZJII0470BE-R CAP CHIP 47P0F +5% -5% 50.0V NPO 0603
C100 C122 C123 C124 C146
C147 C151 C152 C160 C169
C174 C181 C203 C216 C219
C235 C237 C239 C243 C244
C254 C266 C270 C286 C291
C293 C295 C297 C300 C317
C321 C323 C337 C338 C383
C417 C427 C428 C437 C446
C447 C455 C464 C470 C471
C480 C481 C504 C510 C581
C591 C604 C664 C689 C723
C742 C823 C826 C901 C905
C919 C920 C921 C945 C979
C984 C985
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C395 CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C557 H03-CEZXA0479MN-R CM 47MI0F +80%-20% 5.5V 70C SCDA5R5473V
Semiconductors
Q851 H03-TRKTA107MNA-R TR-SLPSWA KRA107M PNP
Q511 H03-TRMPSA06NNA-R TR-SLPLF MPSA06 NPN 500MI0A TO-92
D403 D410 D507 D508 D603
D700
H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
D401 D402 H03-DSUDZ09V1NB-R D-ZENER UDZS 9.1B 9.1V 200MI0W
IC53 H03-IC24LC256D2-R IC CMOS SERIAL EEPROM 24LC256T-I/SNG SOIC-8P(150MIL)
IC16 H03-IC24LC64ID2-R 24LC64-I/SNG SOIC-8P(150mil) Serial EEPROM
IC45 H03-IC74AHC1G14-R 74AHC1G14 SOT753 Inverting Schmitt trigger
IC78 H03-IC74LVC254D-R ICSN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer
IC50 H03-IC74VC244G5-R IC-LOGIC 74VHC244MX or 74VHC244MX_NL M20B INVERTER CMOS
AVR745
harman/kardon
105
