Harman Kardon AVR 745 Service Manual

Ref. Designator Part Number
Description
DSP PCB ASS'Y
IC23 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC94 H03-ICM317TO252-R IC 3-TERMINAL POS VOL REG NJM317DL1-TE1 TO-252
Q401 Q407 Q408 Q411 Q502
Q503 Q505 Q506 Q509 Q512
Q700
H03-TSKRC107SND-R KRC107S SOT-23 NPN
D405 D406 D415 D416 H03-DS05GBUSCNB-R DIODE PG05GBUSC
D338 D404 D409 D414 D509
D510
H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
D339 H03-DSUDZ05V1NB-R DIODE ZENER UDZ5.1B 5.1V 200MI0W
IC22 H03-IC70F3261E1-R UPD70F3261YGC-8EA-A LQFP100 32-bit single-chip microcontroller
IC96 H03-IC74CB3T3D2-R IC SN74CB3T3306DCTR SSOP-8 Dual Bus Switch Voltage Translator
IC57 IC59 H03-IC74LC1G1DL-R IC SINGLE SCHMITT BUFFERSN74LVC1G17DBVR SOT(SOT-23)DBV
IC17 IC18 IC19 H03-IC74LVC254D-R ICSN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer
IC10 IC12 IC38 IC39 H03-ICAD1852JDA-R IC 192Khz 24bit DAC AD1852JRSZ SSOP28
IC20 H03-ICAK4114VE8-R IC 192Khz 24bit INTERFACEAK4114VQ LQFP48
IC25 IC26 IC27 IC37 H03-ICAK5385ADA-R IC A/D CONVERTORAK5385AVF VSOP28
IC92 H03-ICAT49BV163-R IC FLASH MEMORY AT49BV163DT(or AT)-70TU TS
IC21 H03-ICBU4051BD3-R IC ANALOG MPX/DEMPX BU4051BCF SOP16
IC35 H03-ICBU4053BB4-R IC BU4053BCF SOP16 ANALOG MPX/DEMPX
IC24 IC28 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC40 H03-ICDS1233ADK-R IC 3.3V ECONO RESET DS1233AZ-15+TR SOT-223
IC93 H03-ICK4S1616UC-R K4S161622H-UC60 OR UC80 TSOP50 512K x 16Bit x 2 Banks SDRAM
IC13 IC41 IC42 IC43 IC44 IC49
IC60 IC61 IC62 IC63 IC64 IC65
IC66 IC67 IC68 IC69 IC71 IC72
H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
IC74 IC75 H03-ICM74H04MD4-R IC-LOGIC M74HCU04M1R INVERTER HCT
IC11 IC31 H03-ICS4391AKZZ-R CS4391A-KZZ SOP20 24-BIT, 192 kHz STEREO DAC WITH VOLUME CONTROL
IC36 H03-ICTC9162CDA-R IC CMOS TC9162CFG SOP28 HIGH VOLTAGE ANALOG FUNCTION SWITCH
ARRAY
IC91 H03-ICTMS320DNN-R IC FLOATING-POINT DSPTMS320DA610-250 PQFP208
IC14 H03-ICTUSB320EB-R ICTUSB3200A TQFP52 USB Streaming Controller
IC15 H03-ICXMDIC00E8-R IC DIGITAL TRANCEIVERXMDIC QFP48
IC51 IC52 H03-ICC1G125DCK-R IC SINGLE BUS BUFFER GATE SN74LVC1G125DCKT SOT(SC-70)DCKT
Q710 Q188 Q200 Q405 Q409
Q500 Q501 Q504 Q507 Q508
Q510 Q513 Q514
H03-TSKRC107SND-R KRC107S SOT-23 NPN
IC30 H03-ICCJT1173N3-R IC VOLTAGE REGULATOR CJT117-3.3 SOT-223
D501 H03-DURS10040NA-R RS1004 RS-10
IC85 H03-ICPC17T10B1-R IC PHOTOCOUPLER PC-17T1 DIP4 KODENSHI
Resistors
RS14 RS16 RS17 RS18 RS19 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
R271 RS1AD0183NA-R 18K ohm 1/16W 1% 0603
R234 RS1AD3091NA-R RES CHIP 3.09K OHM 1/16W 1% 0603
R213 RS1AD3321NA-R RES CHIP 3.32K OHM 1/16W 1% 0603
R214 RS1AD4751NA-R RES.CHIP 4.75K 1/16W +/-1% 0603
C290 C294 C296 C298 R219
R310 R311 R631 C603 R953
R954 J201 J202 J407 J408
J409
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R310 R311 RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603 USA ONLY
R244 R248 R274 R278 R302
R303 R503 R504 R505 R507
R508 R707 R708 R709
RS3AD0100NA-R RMGCFMIC 10R0 OHM +5% 0603
R254 R255 R289 R290 R291
R292 R316 R405 R417 R418
R424 R426 R445 R467 R478
R511 R512 R569 R609 R610
R611 R612 R932 R570
RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
AVR745
harman/kardon
106
