Harman Kardon AVR 745 Service Manual

Ref. Designator Part Number
Description
DSP PCB ASS'Y
R104 R105 R256 R257 R284
R286 R293 R295 R337 R487
R604 R648 R655 R703 R704
R743 R803 R804 R807 R808
R811 R815 R816 R968
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R281 R515 RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603 EUROPE ONLY
R101 R107 R108 R109 R110
R183 R187 R188 R190 R191
R193 R264 R267 R296 R304
R307 R308 R322 R323 R324
R326 R327 R328 R427 R428
R441 R442 R443 R444 R457
R458 R459 R460 R463 R464
R469 R470 R473 R474 R475
R476 R489 R490 R491 R492
R495 R496 R685 R923 R969
R991 R992 R993 R994 R995
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R141 R142 R151 R152 R177
R178 R201 R202 R236 R419
R466 R556 R653 R702 R706
R724 R730 R801 R802 R805
R806 R809 R813 R814
RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R319 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R513 R514 R725 RS3AD0122NA-R RMGCFMIC 1K2 OHM +5% 0603
R571 RS3AD0151NA-R RMGCFMIC 150R0 OHM +5% 0603
R163 R285 R737 R740 RS3AD0153NA-R RES CHIP,15K 1/16W,+/-5%,0603.
R919 RS3AD0182NA-R RES CHIP,1.8K,1/16W,+-5%,0603.
R119 R120 R124 R125 R133
R134 R137 R138 R155 R156
R159 R160 R169 R170 R173
R174 R221 R222 R225 R226
R590 R591
RS3AD0202NA-R RMGCFMIC 2K0 OHM +5% 0603
R429 R430 R461 R462 R471
R472 R493 R494
RS3AD0203NA-R RMGCFMIC 20K0 OHM +5% 62MI5W 0603
R716 RS3AD0220NA-R RES CHIP,22R 1/16W +/-5%,0603
R639 RS3AD0221NA-R RMGCFMIC 220R0 OHM +5% 0603
R262 R263 R269 R270 R279
R309 R553 R554 R664 R924
RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R181 R182 R184 R189 R192
R194 R198
RS3AD022ANA-R RMGCFMIC 2R2 OHM +5% 0603
R723 R277 RS3AD0241NA-R RES CHIP 240 OHM 1/16W +/-5% 0603
R812 RS3AD0362NA-R RMGCFMIC 3K6 OHM +5% 0603
R247 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R726 RS3AD0391NA-R RMGCFMIC 390R0 OHM +5% 0603
R920 R921 R922 RS3AD0392NA-R RMGCFMIC 3K9 OHM +5% 0603
R568 RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R637 R638 R931 RS3AD0471NA-R RMGCFMIC 470R0 OHM +5% 0603
R122 R123 R130 R135 R158
R166 R171 R224 R229 R240
R241 R245 R407 R408 R420
R425 R440 R588 R603 R967
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R301 R431 R432 R433 R434
R435 R436 R437 R438 R996
RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R113 R114 R143 R144 R149
R150 R179 R180 R199 R200
R299 R597
RS3AD0561NA-R RES CHIP,560R 1/16W +/-5%,0603
R810 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
R273 R619 R632 R633 R700
R701 R705
RS3AD0750NA-R RMGCFMIC 75R0 OHM +5% 0603
R821 R822 R823 R824 R825
R826 R827
RS3AD0823NA-R RES,CHIP 82K,1/16W,+/-5%,0603
R654 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R651 RS3AD0680NA-R RMGCFMIC 68R0 OHM +5% 0603
RS11 RS12 RS13 RS15 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
AVR745
harman/kardon
107
