Harman Kardon AVR245 Service Manual

Surround
Mode
Tuning
Preset Stations
Surround
Select
Tuner Band
Tuning
Mode
Source
Select
Headphone
Jack/Ezet+
Microphone
Input
Digital
Audio Inputs
Video Inputs
Analog Audio
Inputs
Navigation
Tone Mode
Speaker Size
Setup
Delay
Digital Input
Select
Power
Indicator
Main Power
Switch
Standby/On
Switch
Volume
Source
Indicators
Message Display
Surround Mode Indicators
Speaker/Channel
Input Indicators
Channel Level
Adjust
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com.
HKP1477AVR245om 8/29/06 5:45 PM Page 8
7
AVR245 harman/kardon

Harman Kardon AVR245 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Weight	12.7 kg
Type	AV Receiver
Input Sensitivity	200mV
Tone control	Bass, Treble
Headphone output	Yes
Decoder	Dolby Digital, DTS
DSP	Yes
Tuner type	AM/FM
Number of preset stations	30
Remote control	Yes
Width	440 mm
Height	165 mm
Depth	382 mm
Total Harmonic Distortion	0.07%
Dimensions	440 x 165 x 382 mm
Power Output	50 watts per channel
Input Impedance	47kohm
Digital inputs	Optical, Coaxial
Digital outputs	1 Optical
Frequency Response	10Hz - 100kHz
Video Inputs	Composite, S-Video, Component
Video Outputs	Composite, S-Video, Component
Audio Outputs	7.1 channel
Audio Inputs	Analog
