Harman Kardon AVR245 Service Manual

Ref. Designator Part Number
Description
Qty
PCB , POWER TRANS CUP11916-3,4
HVDKBU804F DIODE , BRIDGE BRIDGE DIODE 1
Q104 HVTKSC2316YT TRANSISTOR NPN KSC2316Y 1
Q911 HVTKTA1267YT TRANSISTOR PNP KTA1267Y 1
Q912 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1
Q913 HVTKTC3198YT TRANSISTOR NPN KTC3198Y 1
Resistors
R101 CRD25FJ3R3T RES , CARBON 3.3 OHM 1/4W J 1
R104 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1
R105 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1
R106 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R107 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R114 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1
R115 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1
R116 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R117 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R118 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R119 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R108 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J 1
R109 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R110 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J 1
R112 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R113 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1
R120 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R917 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R918 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R919 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R920 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R921 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R922 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R923 CRD25TJ153T RES , CARBON 15K OHM 1/5W J 1
R924 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R925 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R926 CRD25TJ103T RES , CARBON 10K OHM 1/5W J 1
R927 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R928 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
Miscellaneous
CMY1A219 HEAT SINK (BRIDGE DIODE) HEAT SINK 1
CTB3+12JR SCREW SCREW 1
CMY1A219 HEAT SINK (BRIDGE DIODE) HEAT SINK 1
CTB3+12JR SCREW SCREW 1
BN96 CWB1C909150BM WIRE ASS'Y WIRE 1
BN99 CWB1B908270EN WIRE ASS'Y WIRE 1
CN13 CJP05GA01ZY CON WAFER YMW025-05R WAFER 1
CN19 CJP03GA90ZY WAFER WAFER 1
CN20 CJP04GA90ZM WAFER WAFER 1
CN81 CJP08GA01ZY WAFER, STRAIGHT, 8PIN WAFER 1
PCB , DIGITAL IN/OUT CUP11916-1
C750 CCEA1CH101T CAP , ELECT 100UF 16V 1
C751 CCEA1CH101T CAP , ELECT 100UF 16V 1
C753 HCBS1H181KBT CAP , CERAMIC 180PF 50V 1
C754 HCBS1H181KBT CAP , CERAMIC 180PF 50V 1
71
AVR245 harman/kardon

Harman Kardon AVR245 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Weight	12.7 kg
Type	AV Receiver
Input Sensitivity	200mV
Tone control	Bass, Treble
Headphone output	Yes
Decoder	Dolby Digital, DTS
DSP	Yes
Tuner type	AM/FM
Number of preset stations	30
Remote control	Yes
Width	440 mm
Height	165 mm
Depth	382 mm
Total Harmonic Distortion	0.07%
Dimensions	440 x 165 x 382 mm
Power Output	50 watts per channel
Input Impedance	47kohm
Digital inputs	Optical, Coaxial
Digital outputs	1 Optical
Frequency Response	10Hz - 100kHz
Video Inputs	Composite, S-Video, Component
Video Outputs	Composite, S-Video, Component
Audio Outputs	7.1 channel
Audio Inputs	Analog
