Harman Kardon AVR245 Service Manual

Ref. Designator Part Number
Description
Qty
PCB , BIAS TR CUP11916-2
R879 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R880 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1
R882 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R883 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R884 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R885 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R886 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R887 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R888 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
VR81 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
VR82 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
VR83 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
VR84 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
VR85 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
VR86 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
VR87 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221 1
Miscellaneous
CN31 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN32 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN33 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN34 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN35 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN36 CJP02GA19ZY WAFER, 2PIN WAFER 1
CN37 CJP02GA19ZY WAFER, 2PIN WAFER 1
PCB , REGULATOR CUP11916-5,6
C901 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C902 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C903 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C905 CCEA1CH101T CAP , ELECT 100UF 16V 1
C906 CCEA1CH101T CAP , ELECT 100UF 16V 1
C907 CCEA1CH101T CAP , ELECT 100UF 16V 1
C908 CCEA1CH101T CAP , ELECT 100UF 16V 1
C910 CCEA1VH221T CAP , ELECT 220UF 35V 1
C911 CCEA1EH471E CAP , ELECT 470UF/25V 1
C935 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C936 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C937 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V 1
C938 CCEA1CH101T CAP , ELECT 100UF 16V 1
C939 CCEA1EH101T CAP , ELECT 100UF 25V 1
C940 CCEA1EH101T CAP , ELECT 100UF 25V 1
C912 CCEA0JKR3222E CAP , ELECT 2200UF 6.3V 1
C929 CCEA1VH102E CAP , ELECT 1000UF 35V 1
C930 CCEA1VH102E CAP , ELECT 1000UF 35V 1
C941 CCEA1CH682E CAP , ELECT 6800UF 16V 1
IC89 HVIL7805CP I.C, REGULATOR +5V ST 1
IC90 HVIL7815CP I.C, REGULATOR +15V ST 1
IC91 HVIL7915CP I.C, REGULATOR -15V ST 1
IC92 HVIL7805CP I.C, REGULATOR +5V ST 1
IC93 HVIL7905CP I.C, REGULATOR -5V ST 1
IC94 HVIL7805CP I.C, REGULATOR +5V ST 1
IC95 HVIL7812CP I.C , REGULATOR +12V L7812(ST) 1
D901 HVD1N5819T DIODE , SCHOTTKY 1N5819 1
R912 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
73
AVR245 harman/kardon

Harman Kardon AVR245 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Weight	12.7 kg
Type	AV Receiver
Input Sensitivity	200mV
Tone control	Bass, Treble
Headphone output	Yes
Decoder	Dolby Digital, DTS
DSP	Yes
Tuner type	AM/FM
Number of preset stations	30
Remote control	Yes
Width	440 mm
Height	165 mm
Depth	382 mm
Total Harmonic Distortion	0.07%
Dimensions	440 x 165 x 382 mm
Power Output	50 watts per channel
Input Impedance	47kohm
Digital inputs	Optical, Coaxial
Digital outputs	1 Optical
Frequency Response	10Hz - 100kHz
Video Inputs	Composite, S-Video, Component
Video Outputs	Composite, S-Video, Component
Audio Outputs	7.1 channel
Audio Inputs	Analog
