Harman Kardon AVR245 Service Manual

FM Antenna
XM
Antenna
Jack
AM Antenna
Video 2
A/V
Inputs
Video 1
A/V
Outputs
Video 3
A/V
Inputs
Video 1
A/V
Inputs
Video
Monitor
Outputs
DVD A/V
Inputs
Component
Video
Inputs
(1, 2 & 3)
Component
Video
Monitor
Outputs
AC Power
Cord
RS-232
Serial Port
Coaxial Digital
Audio
Inputs
(1 & 2)
RS-232
Mode
The
Bridge/
DMP
Input
RS-232
Reset
HDMI
Output
HDMI 2
Input
HDMI1
Input
Subwoofer
Output
Preamp
Outputs
Front Speaker
Outputs
Surround
Speaker
Outputs
6-/8-
Channel
Inputs
Surround
Back/Multiroom
Speaker Outputs
Surround
Back/
Multiroom
Preamp
Outputs
Center Speaker
Outputs
Switched AC
Accessory
Outlet
Coaxial
Digital
Audio
Output
Optical Digital
Audio Inputs (1 & 2)
Optical Digital
Audio Output
CD
Inputs
Multiroom
IR Input
Remote
IR Input
Remote
IR Output
Tape
Outputs
Tape
Inputs
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com.
HKP1477AVR245om 8/29/06 5:45 PM Page 11
10
AVR245 harman/kardon

Harman Kardon AVR245 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Weight	12.7 kg
Type	AV Receiver
Input Sensitivity	200mV
Tone control	Bass, Treble
Headphone output	Yes
Decoder	Dolby Digital, DTS
DSP	Yes
Tuner type	AM/FM
Number of preset stations	30
Remote control	Yes
Width	440 mm
Height	165 mm
Depth	382 mm
Total Harmonic Distortion	0.07%
Dimensions	440 x 165 x 382 mm
Power Output	50 watts per channel
Input Impedance	47kohm
Digital inputs	Optical, Coaxial
Digital outputs	1 Optical
Frequency Response	10Hz - 100kHz
Video Inputs	Composite, S-Video, Component
Video Outputs	Composite, S-Video, Component
Audio Outputs	7.1 channel
Audio Inputs	Analog
