Ref. Designator Part Number

Description

Qty

PCB , IPOD CUP11834Y

C423 CCUS1H220JA CAP , CHIP 22PF 1

C424 CCUS1H220JA CAP , CHIP 22PF 1

C425 CCUS1H223KC CAP , CHIP 0.022UF 1

C426 CCUS1H223KC CAP , CHIP 0.022UF 1

C427 CCUS1H223KC CAP , CHIP 0.022UF 1

C430 CCEA1AH331T CAP , ELECT 330UF 10V 1

C431 CCEA1CH221T CAP , ELECT 220UF 16V 1

C432 HCEC1CRV2220T CAP , ELEC (SMD) 22UF/16V 1

C433 CCEA1CKS101T CAP , ELECT 100UF 16V 1

C435 CCUS1H070DA CAP , CHIP 7PF 1

C436 CCUS1H120JA CAP , CHIP 12PF 1

C440 CCUS1H223KC CAP , CHIP 0.022UF 1

C445 HCEC1CRV2220T CAP , ELEC (SMD) 22UF/16V 1

Semiconductors

D400 CVD1SS355T CHIP , DIODE 1SS355T 1

D401 CVD1SS355T CHIP , DIODE 1SS355T 1

D402 CVD1N4003SRT RECT , DIODE 1N4003 1

IC41 HVINJM2068MDTE1 I.C , DUAL OP AMP JRC 1

IC42 HVINJM2068MDTE1 I.C , DUAL OP AMP JRC 1

IC43 HVINJM2137MTE1 I.C , DUAL OP AMP JRC 1

Q402 HVTKRC102S TRANSISTOR , CHIP NPN KRC102S 1

Resistors

R400 CRJ10DJ4R7T RES , CHIP 4.7 OHM 1

R401 CRJ10DJ4R7T RES , CHIP 4.7 OHM 1

R402 CRJ10DF5493T RES , CHIP 543K OHM 1% 1

R403 CRJ10DJ0R0T RES , CHIP 0 OHM 1

R404 CRJ10DJ103T RES , CHIP 10K OHM 1

R405 CRJ10DJ103T RES , CHIP 10K OHM 1

R406 CRJ10DJ474T RES , CHIP 470K OHM 1

R407 CRJ10DJ474T RES , CHIP 470K OHM 1

R421 CRJ10DJ222T RES , CHIP 2.2K OHM 1

R422 CRJ10DJ474T RES , CHIP 470K OHM 1

R430 CRJ10DJ473T RES , CHIP 47K OHM 1

R431 CRJ10DJ473T RES , CHIP 47K OHM 1

R432 CRJ18AJ221T RES , CHIP 220 OHM,2012 SIZE 1

R433 CRJ18AJ221T RES , CHIP 220 OHM,2012 SIZE 1

R434 CRJ10DJ103T RES , CHIP 10K OHM 1

R435 CRJ10DJ103T RES , CHIP 10K OHM 1

R436 CRJ10DJ222T RES , CHIP 2.2K OHM 1

R437 CRJ10DJ222T RES , CHIP 2.2K OHM 1

R438 CRJ10DJ222T RES , CHIP 2.2K OHM 1

R439 CRJ10DJ222T RES , CHIP 2.2K OHM 1

R440 CRJ10DJ220T RES , CHIP 2.2K OHM 1

R441 CRJ10DJ472T RES , CHIP 4.7K OHM 1

R442 CRJ10DJ472T RES , CHIP 4.7K OHM 1

R443 CRJ10DJ202T RES , CHIP 2K OHM 1

R444 CCUS1H151JA CAP , CHIP 150PF 1

R445 CRJ10DJ202T RES , CHIP 2K OHM 1

R446 CRJ10DJ431T RES , CHIP 430 OHM 1

R447 CRJ10DJ821T RES , CHIP 820 OHM 1

R449 CRJ10DJ0R0T RES , CHIP 0 OHM 1

R453 CRJ10DJ220T RES , CHIP 22 OHM 1

AVR245 harman/kardon
