harman/kardon
TECH TIPS
Troubleshooting tips and solutions to common service problems
AVR Test Cable Kit Now Available
For models: AVR35/45/65 TIP# HKTT2002-01
AVR100/200/300/500/7000
AVR110/210/310/510
AVR120/220/320/520
Complaint:
The components on many of these PCB’s can’t be accessed with a test probe or other device because
the boards are mounted so close together. If the board is physically removed, signal & power to the
board is lost and the board/component cannot be tested.
Solution:
Order h/k extension cable kit #AVR-CABLEASSYII. This kit, consisting of various ribbon cable
assemblies, will allow you to extend the connectors so any PCB can be removed from the unit and still
be “live”.
AVR310 harman/kardon
