Harman Kardon CDR2 Service Manual

Ref. No.
Part No.
Description
564-036D
PLUG CONTACT CORD,PHONE
564-036J
CORD DIGIATL 1.5M 1365#30
6852R-N001A
CORD 1.5M NAMIL REMOTE CONTROL
255-717A
HEAT SINK DIODE(GSA-PA10/FA-5000)
PT901
6170S-I03AH
TRANSFORMER,POWER
6850R-GZ20Y
CABLE,FLAT
CAPACITORS
C101,106,120,123,127
0CE4766J618
47M SMS 35V M FM(5) TP(5)
C102,104
0CH1102K566
1000PF 50V K X7R(X) 2012 R/TP
C103
0CE4756K618
4.7M SMS 50V M FL TP(5)
C105,108,110,119,122
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C109,239
0CH1103K946
0.01UF 50V Z Y5V(F) 2012 R/TP
C114,115,116,117,131
0CE2266K618
22M SMS 50V M FM5 TP(5)
C118,121,124,125,214
0CH4101K416
100P 50V J NP0 2.0*1.25 R/TP
C126,128,134,135,136
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C129,204,205,209,401
0CE4766J618
47M SMS 35V M FM(5) TP(5)
C130,132,219,240,429
0CH4221K416
220P 50V J 2.0X1.25 R/TP
C133,220,231,425,426
0CE2266K618
22M SMS 50V M FM5 TP(5)
C137,138,139,140,141
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C142,143,144,145,206
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C202,212,411,412,471
0CE1076F618
100M SMS 16V M FM5 TP(5)
C203,218,225,227,416
0CH1821K516
CONDENSER
C207,229,234,238,241
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C208
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C210,211,223,224,408
0CE1076D618
100M SMS 10V M FM5 TP(5)
C213,221,222,415,418
0CH1332K566
3300PF 50V K X7R(X) 2012 R/TP
C217
0CE2276H618
220M SMS 25V FM5 TP(5)
C236,237,427,428
0CQ3921N409
0.0039U 100V J POLY TP
C242,245,402,404,407
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C246,999
0CH1105F946
1UF 16V Z Y5V(F) 2012 R/TP
C247,248,251
0CH4101K416
100P 50V J NP0 2.0*1.25 R/TP
C249
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C250,252
0CH4470K416
47P 50V J NP0 2.0X1.25 R/TP
C405,406
0CE4766J618
47M SMS 35V M FM(5) TP(5)
C409,413,414
0CE1076D618
100M SMS 10V M FM5 TP(5)
C417,419,424
0CH1821K516
CONDENSER
C430
0CH4221K416
220P 50V J 2.0X1.25 R/TP
C472
0CE1076F618
100M SMS 16V M FM5 TP(5)
C473,474
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
COIL,CHOKE
T101,102
6140R-C001A
T3-300 KWANGSUNG 100UH BULK
CONNECTOR
CN105
563-602P
GIL-S/GIL-T 6PIN 60M/M UL1571
CN301
561-640J
GL200-10P-TS P=2.0 HOLDER GSC
CN602
563-602M
GS IL-S10/T10 1571#28 320 28 3
CN606
563-602D
P=2.0 GIL-S08/T08 1571#28 280
PN105
6630S-FB07P
00-6232-016-008-800 ELCO KOREA
PN401
561-711F
*WAFER,G/S GIL-S-06P-S2T2-EF
PN501
561-715F
GIL-G-06P-S3T2-E LG CABLE 6PIN
CHASSIS MISCELLANEOUS
ACDR I/O PART P.C. BOARD
CDR2 harman/kardon
82
