Harman Kardon CDR2 Service Manual
4
of 1
of 1 rating
116 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Ref. No.
Part No.
Description
Q905
0TR103009AE
KRC103M-TP (KRC1203) KEC
Q906,907
0TR130209AA
KTD1302 MUTING TP KEC TO92
CAPACITORS
C801,802,809,810
0CN1040K948
0.1UF 50V Z F TA26 D
C804
0CE1073F638
100M SRE 16V M FM5 TP(5)
C805,806,807
0CN2230H948
0.022M 25V Z F TA26
C811,812,813,814
0CN1010K418
100PF 50V J B TA26
CONNECTOR
CN801
6630S-BC02H
B TO B P=1.25 8 PIN, 53045-081
CN803
563-602M
GS IL-S10/T10 1571#28 320 28 3
CN804
563-602D
P=2.0 GIL-S08/T08 1571#28 280
PN801
6630S-BC01H
B TO B P=1.25 8 PIN, 52061-081
PN8802
6630R-BF03E
JE121-05 JAE EUN 5PIN 2.54MM B
DIGITRON
FLD801
6302S-V007A
16BT-72GNK FUTABA CDR-600
INTEGRAED CURCUITS
IC801,802
0IMA125110A
MN12511 SOP024 TP FLD DRIVE
RMC801
0IRH693840A
RPM6938-V4 3P BK REMOCON MODUL
LED
LD801,802,803,804,805
0DL341829AA
SM3418F2T TP AUK GREEN .
LD806,807,808,809,810
0DL341829AA
SM3418F2T TP AUK GREEN .
LD811,812,813,814,815
0DL341829AA
SM3418F2T TP AUK GREEN .
RESISTORS
R801,802,808,809,813
0RD2201F608
2.2K 1/6
W 5 TA26
R803,810,815
0RD3301F608
3.3K 1/6
W 5 TA26
R804,811,816
0RD4701F608
4.7K 1/6
W 5 TA26
R805,812,817
0RD5601F608
5.6K 1/6
W 5 TA26
R806,818
0RD8201F608
8.2K 1/6
W 5 TA26
R807,819
0RD1502F608
15K 1/6
W 5 TA26
R814
0RD2201F608
2.2K 1/6
W 5 TA26
R820,821,822
0RD1802F608
18K 1/6
W 5 TA26
R823,824
0RD1500F608
150 1/6
W 5 TA26
R825,826,827,828,829
0RD0182F608
18 1/6
W 5 TA26
R830
0RD0182F608
18 1/6
W 5 TA26
R831
0RD0332F608
33 1/6
W 5 TA26
R832
0RD0822F608
82 1/6
W 5 TA26
R833
0RD1000F608
100 1/6
W 5 TA26
SWITCH
SW801,802,803,804,805
558T026A
EVQ-214 04M MATSUSHITA NON 0V
SW806,807,808,809,810
558T026A
EVQ-214 04M MATSUSHITA NON 0V
SW811,812,813,814,815
558T026A
EVQ-214 04M MATSUSHITA NON 0V
SW816,817,818,819,820
558T026A
EVQ-214 04M MATSUSHITA NON 0V
SW821,822
558T026A
EVQ-214 04M MATSUSHITA NON 0V
TRANSISTOR
Q801
0TR102009AE
KRA102M (KRA2202) TP KEC TO
VR802
6110R-RK01B
VOLUME,ROTARY
CAPACITORS
C816
0CN1040K948
0.1UF 50V Z F TA26 D
FRONT P.C. BOARD
VOLUME P.C. BOARD
HEADPHONE P.C. BOARD
CDR2
harm
an/kar
don
85
84
86
Table of Contents
Table of Contents
1
Laser Beam Safety Precautions
2
Handling Laser Pickup
3
Before Repairing the Compact Disc Player
3
Human Body Grounding
3
Safety Precautions
3
Cdr2 Important Notes
4
Specifications
6
Power Switch
7
Status-Mode Indicator
7
Play Deck
7
Front Panel Controls
7
Front-Panel Information Display
9
Rear Panel Connections
11
Remote Control Functions
12
Troubleshooting Guide and Error Messages
14
Top View
15
Internal View
15
Pcb-(Power Switch) Removal
16
Cabinet Top Removal
16
Disassembly Procedures
16
Front Panel Assembly Removal
17
Power Lever Assembly Removal
17
PCB-1(Power) REMOVAL
18
Pcb-2(I/O) Removal
18
Mecha-1 (Cdp) Assembly Removal
19
Mecha-2 (Cdr) Assembly Removal
19
Pcb-3(Cdp) Removal
20
PCB-5 (Front) REMOVAL
20
PCB-7(REC Volume) Removal
20
PCB-6(Headphone) Removal
20
Pcb-4(Cdr) Removal
21
Block Diagram
22
Ak8563
22
IC Pinouts
22
Pin Functions
23
Rl5E808
25
Block Diagram
25
M56788
26
La 6543M
26
Mn12511
27
CXD3011R-1 Block Diagram
28
AK4393 Block Diagram
33
AK5351 Block Diagram
34
Initial Lead-In Operation
37
Trouble List(Circuit)
37
Detailed Troubleshooting Guide
37
No Audio
40
Current Deck Is CDP
40
Current Deck Is CDR
41
Reset or Power Check
42
System Check
43
TOC Is Abnormal
44
Dubbing Is Abnormal
45
Tray Operation Abnormal
46
Sled Motor Operation Abnormal
47
Focus Actuator Operation Abnormal
48
Spindle Motor Operation Abnormal
49
RFDC Output Operation Abnormal
50
Focus Servo Unstable
51
Tracking Servo Unstable
51
Spindle Control Abnormal1
52
Spindle Control Abnormal2
52
Disc Recognition Abnormal
53
Laser Operation Abnormal
55
LD Check (no Reading)
56
LD Check (no Recording)
57
Write Failure
59
Writing Part Check
60
ALPC Logic Circuit Check
61
Asic
64
Bitstr~1
64
U-Com
65
BULLETIN 2000-08 Rev2
66
Bulletin 2001-008
67
TECH TIP HKTT2001-02 Rev1
68
Various Complaints - Tips and Solutions
69
Tech Tip Hktt2003-04
69
Main Section
70
Exploded View/Parts List
70
CD Play Section
71
CD-Record Mechanisms
71
CD Record Section
72
Block Diagrams
73
CD-Play Top Section
76
Pcb Layout
76
CD-Play Bottom Section
77
CD-Record Top Section
78
CD-Record Bottom Section
78
Audio Top Section
79
Audio Bottom Section
79
Front Section
80
Power Section
81
Chassis Miscellaneous
82
Acdr I/O Part P.C. Board
82
Electrical Parts List
82
Power P.C. Board
84
Headphone P.C. Board
85
Front P.C. Board
85
Volume P.C. Board
85
Schematic Diagrams
95
CD Record Tile
101
CD Record - Tile 3
103
CD Recordii - Tile 2
105
CD Play - Tile 1
108
Audio - Tile 1
112
Audio - Tile 2
113
Audio - Tile 3
114
Wiring Diagram
115
Package
116
Harman/Kardon, Inc
116
