Harman Kardon CDR2 Service Manual

Ref. No.
Part No.
Description
CONNECTOR
CN806
6631R-E006A
IL-S/9073AN 6PIN 400M/M UL2547
J801
563-638E
SPECIAL RING TER. AY 1007#24 G
DIODE
ZD801,802
0DZ510009EB
MTZ5.1B 0.5W TP ROHM-K
JACK
JK802
572-359J
SOQ4694-01-4101 K-HOSIDEN H=6.
JK801
6612S-C004A
WA6013-35-40 PARK ELEC ORANGE
VOLUME,ROTARY
VR801
6110R-RK01A
RK09L12B0-500BX2 J-ALPS D=9 H
PN802
561-643C
CONNECTOR 52151-0310 3PIN 2.0MM
LED801
0DL325319AA
LED SPR325MVWT31 GREEN/RED
CAPACITORS
C101,220,223,514,704
0CH1103K562
10000F 50V K X7R(X) 1508 R/TP
C102,116,119,312,420
0CH8107C621
100UF 6.3V M 85STD(CYL) R/TP
C103
0CH1105D942
1UF 10V Z Y5V(F) 1508 R/TP
C104,106,118,210,213
0CH1104K942
0.1UF 50V Z Y5V(F) 1508 R/TP
C105,120,123,201,203
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C107,108,114,117,204
0CH1105F946
1UF 16V Z Y5V(F) 2012 R/TP
C115,411,601
0CH8476F621
47UF 16V M 6666 R/TP
C121,122,207,211,712
0CH4101K412
100P 50V J COG 1.6X0.8 R/TP
C125,126,127
0CH1222K512
2200PF 50V K B 1608 R/TP
C202
0CH4471K412
470PF 50V J NP0 1508 R/TP
C205,212,301,303,308
0CH1105F946
1UF 16V Z Y5V(F) 2012 R/TP
C206,209,214,224,306
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C208,218
0CH4221K412
220P 50V J COG 1.6X0.8 R/TP
C215,219,414
0CH1473H942
0.0470UF 25V Z Y5V(F) 1608 R/T
C216
0CH4151K412
150P 50V J COG 1.6X0.8 R/TP
C217
0CH1332K562
3300P 50V K X7R 1.6X0.8 R/TP
C221,222
0CH4220K442
22PF 50V J N220 1508 R/TP
C304
0CH8227C621
220000000F 6.3V M 105STD(CYL)
C309,510
0CH1105F946
1UF 16V Z Y5V(F) 2012 R/TP
C310
0CH1122K562
1200P 50V K X7R 1.6X0.8 R/TP
C311,404,417,421,503
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C401,402,403,405,406
0CH1104K942
0.1UF 50V Z Y5V(F) 1508 R/TP
C407,408,409,412,509
0CH1104K942
0.1UF 50V Z Y5V(F) 1508 R/TP
C410
0CH8107F621
100UF 16V M 6666 R/TP
C415,416
0CH1823K946
0.0820UF 50V Z Y5V(F) 2012 R/T
C418
0CH1152K566
1500PF 50V K X7R(X) 2012 R/TP
C419
0CH1683H566
0.0680UF 25V K X7R(X) 2012 R/T
C501,502
0CH4150K472
15PF 50V J N750 1508 R/TP
C504,507,603
0CH8107C621
100UF 6.3V M 85STD(CYL) R/TP
C505,506,508,511,513
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C515,602,701,702,703
0CH1104K942
0.1UF 50V Z Y5V(F) 1508 R/TP
C604
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C705,706,707,708,709
0CH1103K562
10000F 50V K X7R(X) 1508 R/TP
C710,711,716,717,718
0CH1103K562
10000F 50V K X7R(X) 1508 R/TP
C713,714,715,724,725
0CH4101K412
100P 50V J COG 1.6X0.8 R/TP
C719,720,721,722,723
0CH1103K562
10000F 50V K X7R(X) 1508 R/TP
LED P.C. BOARD
PLAY P.C. BOARD
CDR2 harman/kardon
86
