Harman Kardon CDR2 Service Manual

Ref. No.
Part No.
Description
C726,727,728,729
0CH4101K412
100P 50V J COG 1.6X0.8 R/TP
COIL
L301,401
6140H-B003G
NLC322522T-100K 10MH TDK
L501
6140H-B003G
NLC322522T-100K 10MH TDK
CONNECTOR
PN201
6630R-FB02Q
04-6232-117-008-800 ELCO 17PIN
PN301
6630R-FB02D
04-6232-104-008-800 ELCO 4PIN
PN302
6630R-FB06F
04-6232-106-102-800 ELCO 6PIN
PN401
6630R-FB02M
04-6232-113-008-800 ELCO 13PIN
PN601
6630R3S006E
GT200 LG CABLE 9PIN 2MM STRAIG
PN602
6630R3S006D
GT200 LG CABLE 8PIN 2.0MM STRA
PN603,606
6630R3S006C
GT200 LG CABLE 10PIN 2.0MM STR
PN604
6630R3S006A
GT200 LG CABLE 6PIN 2.0MM STRA
PN605
6630HXC126A
04-6232-126-008-800 ELCO 26PIN
PN609
6630R-FB02F
04-6232-106-008-800 ELCO 6PIN
DIODE
D201
0DS121009AA
KDS121 TP KEC UMT 85V 300MA 2A
D502
0DD187009AC
KDS187 CHIP KEC TP KEC
FILTER(CIRC)
L203
6140H-A001A
BEAD C,HH-1H4532-121JT.CERATEH
INTEGRAED CURCUITS
IC101
0ISO255700A
CXA2557R 48 QFP BK RF
IC102,402,403
0IJR210000A
NJM2100M-TE1-DMP,OP AMP,JRC
IC201
0ISO301110A
CXD3011R-1 144,LQFP BK DSP
IC301
0IMI567880A
M56788FP 42 SSOP TP DRIVE
IC302
0ITO453000C
TC4W53FU SSOP 8PIN
IC401
0ISA119950A
LB11995H-TLM 28P HSOP TP MOTOR
IC501
0IHI643062A
HD64F3062FBL20 FB-100B BK CD-R
IC502
0ITR613002C
XC61AN3002PR(SOT89) 3V 3K/TP
IC601
0IRH393900A
BA3939FP-E2
IC602
0IRH405320A
BU4053BCF-E2 16PIN,SOIC TP TTL
RESISTORS
R101,102,103
0RH0222C622
22 1/16W 5 D.R/TP
R104,105,217,402
0RH4702C622
47K 1/16W 5 D.R/TP
R106,108,147,148,554
0RH0000C622
0 1/16W 5 D.R/TP
R113,140,303,428,514
0RH1001C622
1K 1/16W 5 D.R/TP
R114,117,201,213,310
0RH2202C622
22K 1/16W 5 D.R/TP
R115,116,156,157,229
0RH1003C622
100K 1/16W 5 D.R/TP
R122,419,420
0RH3902C622
39K 1/16W J D.R/TP
R124,125,126,127,131
0RH1002C622
10K 1/16W 5 D.R/TP
R130,426
0RH5601C622
5.6K 1/16W 5 D.R/TP
R132,304
0RH2701C622
2.7K 1/16W 5 D.R/TP
R138,141,203,214,224
0RH1002C622
10K 1/16W 5 D.R/TP
R139
0RH3901C622
3.9K 1/16W 5 D.R/TP
R142,222,223,411,412
0RH3301C622
3.3K 1/16W 5 D.R/TP
R146,427,429
0RH2201C622
2.2K 1/16W 5 D.R/TP
R150,151,153,422,525
0RH2702C622
27K 1/16W 5 D.R/TP
R155
0RH6802C622
68K 1/16W 5 D.R/TP
R202,208,216,227,315
0RH3302C622
33K 1/16W 5 D.R/TP
R218,302,308
0RH1503C622
150K 1/16W 5 D.R/TP
R219,566
0RH4703C622
470K 1/16W 5 D.R/TP
CDR2 harman/kardon
87
