Harman Kardon CDR2 Service Manual

Ref. No.
Part No.
Description
R220
0RH1504C622
1.50M 1/16W 5% D R/TP
R221
0RH2203C622
220K 1/16W 5 D.R/TP
R228,421,423,425,523
0RH1002C622
10K 1/16W 5 D.R/TP
R230,231
0RH2200C622
220 1/16W 5 D.R/TP
R232,233,406,407,565
0RH1500C622
150 1/16W 5 D.R/TP
R234,417,524,541,542
0RH4700C622
470 1/16W 5 D.R/TP
R235,236,239,241,242
0RH1000C622
100 1/16W 5 D.R/TP
R237
0RH6800C622
680 1/16W 5 D.R/TP
R301,307
0RH5602C622
56K 1/16W 5 D.R/TP
R305,306,563,564
0RH1003C622
100K 1/16W 5 D.R/TP
R311,314,403,404,405
0RH1000C622
100 1/16W 5 D.R/TP
R312,424
0RH1502C622
15K 1/16W 5 D.R/TP
R313,316,317,418,538
0RH2202C622
22K 1/16W 5 D.R/TP
R408,409,410
0RH0101G622
1 OHM 1 / 4 W 3216 5% D R/TP
R413,414,522,533
0RH3301C622
3.3K 1/16W 5 D.R/TP
R415,416
0RH8201C622
8.2K 1/16W 5 D.R/TP
R501,504,505,506,512
0RH3300C622
330 1/16W 5 D.R/TP
R502,503,507,508,509
0RH1000C622
100 1/16W 5 D.R/TP
R510,536,537,544,547
0RH1000C622
100 1/16W 5 D.R/TP
R513,518,519,520,527
0RH3300C622
330 1/16W 5 D.R/TP
R515,516,517,521
0RH1001C622
1K 1/16W 5 D.R/TP
R526
0RH8202C622
82K 1/16W 5 D.R/TP
R528,534,539,540
0RH1002C622
10K 1/16W 5 D.R/TP
R535,543,545,546,548
0RH3300C622
330 1/16W 5 D.R/TP
R549,550,552,561
0RH3300C622
330 1/16W 5 D.R/TP
R555
0RH0000C622
0 1/16W 5 D.R/TP
R556,601
0RH4701C622
4.7K 1/16W 5 D.R/TP
R557,558,567,568,602
0RH1000C622
100 1/16W 5 D.R/TP
R603,604,605,606,607
0RH1000C622
100 1/16W 5 D.R/TP
RESONATOR
X501
6212HA0202A
CSACV20.00MXJ040-TC20 MURATA 2
X201
6212HA3382A
CSACV33.86MX040-TC20 MURATA 33
TRANSISTOR
Q101
0TR103709BB
2SA1037K-Q CHIP ROHM-J
Q401,403
0TR130409BA
KTD1304S TP KEC SOT-23 MUTING
CAPACITORS
C102,656
0CH1105F946
1UF 16V Z Y5V(F) 2012 R/TP
C103,108,923,940
0CH8107F621
100UF 16V M 6666 R/TP
C107
0CH8227C621
220000000F 6.3V M 105STD(CYL)
C109,301,302,303,304
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C111
0CH7476C621
47UF 6.3V M 3528 TP(-)
C112,113,212,216,217
0CH1104H942
0.1000UF 25V Z Y5V(F) 1508 R/T
C114,201,204,213,214
0CH1104K942
0.1UF 50V Z Y5V(F) 1508 R/TP
C117,240,253,305,306
0CH1104K946
0.1UF 50V Z Y5V(F) 2012 R/TP
C202,203
0CH4150K412
15P 50V J COG 1.6X0.8 R/TP
C205,206
0CH4050K012
0.5F 50V C NP0 1508 R/TP
C207
0CH4101K412
100P 50V J COG 1.6X0.8 R/TP
C208,318,324,624
0CH4101K412
100P 50V J COG 1.6X0.8 R/TP
C209,267,401,531,588
0CH7106C611
10UF 6.3V M 3216 TP(-)
C210
0CH1683F562
68000F 16V K X7R(X) 1508 R/TP
REC P.C. BOARD
CDR2 harman/kardon
88
