Harman Kardon CDR2 Service Manual

Ref. No.
Part No.
Description
IC211,405
0INS740400Y
74VHC04MTCX 14TSSOP TP HEX INV
IC212,555,761,854
0ITO453000C
TC4W53FU SSOP 8PIN
IC213
0INS704500C
NC7SZ04M5X 5P SOT23-5 TP INVER
IC214
0ITO704000A
TC7S04F INVERTER(GE85L)
IC301
0IXL103144A
XCS10-3TQ144C 144QFP BK FPGA
IC302
0IWI242573A
W24257AS-35 (TAPE&REEL) 1K/TP
IC303,507
0ITO704000A
TC7S04F INVERTER(GE85L)
IC304,305
0IRH405320A
BU4053BCF-E2 16PIN,SOIC TP TTL
IC306
0ICB842000A
CS8420-CS 28L SOIC TP DIGITAL
IC307
0IRH405300A
BU4053BCFV 16P,SSOP TP TRIPLE
IC401,404,407
0INS740800P
74VHC08MTCX 14TSSOP TP QUAD 2-
IC402
0ITO786000C
TC7SH86F SSOP 5P TP EX-OR GATE
IC403,553,603
0IRH405300A
BU4053BCFV 16P,SSOP TP TRIPLE
IC406,609,905
0INS786500A
NC7SZ86M5X 5P SOT23-5 TP 2-INP
IC409
0INS743200S
74VHC32MTCX 14TSSOP TP QUAD 2-
IC501
0ISO301110A
CXD3011R-1 144,LQFP BK DSP
IC503
0IMI623520B
M62352GP 20P SSOP TP 8BITS 12C
IC506,614
0ITO466000F
TC4W66FU SSOP8-P TP DUAL S/W
IC551
0ISA119950A
LB11995H-TLM 28P HSOP TP MOTOR
IC552,610,910
0IJR340300A
NJM3403AV-TE1 OP AMP
IC556
0IJR210000B
NJM2100V DUAL OP AMP,JRC
IC601
0IAK856300A
AK8563 80,LQFP BK ANALOG SIGSA
IC604
0IET224500A
EL2245CS SO8 TP ALPC 2CH OP AM
IC605
0IRH406600A
BU4066BCFV. 14P,SSOP TP QUAD A
IC608,702,912
0IJR341400C
NJM3414AM-TE1,3K/REEL. JRC
IC617,703,904
0IJR290300D
NJM2903V-TE1 8P SSOP TP COMPAR
IC701,903
0IJR340300A
NJM3403AV-TE1 OP AMP
IC760
0ITO708000D
TC7W08FUDUAL 2 INPUT AND GATE
IC851
0IRH393900A
BA3939FP-E2
IC852,853,913
0IJR341400C
NJM3414AM-TE1,3K/REEL. JRC
IC901
0ISA654300A
LA6543M-TLM MFP-36S-LF TP 4CH
IC902,909
0IJR780800C
NJM7808DLA 3 TP REGULATOR
IC908
0ITO466000F
TC4W66FU SSOP8-P TP DUAL S/W
INDUCTOR
L501
0LCZB00005A
HB-1M1608-601JT CERATECH 600 O
RESISTORS
R101
0RH8202C622
82K 1/16W 5 D.R/TP
R102,238,417,580,611
0RH0000C622
0 1/16W 5 D.R/TP
R103,711
0RH2702C622
27K 1/16W 5 D.R/TP
R106,221,222,234,235
0RH1002C622
10K 1/16W 5 D.R/TP
R110,111,113,114,226
0RH1000C622
100 1/16W 5 D.R/TP
R112,202,229,245,246
0RH1000C622
100 1/16W 5 D.R/TP
R118,252,276,334,574
0RH4701C622
4.7K 1/16W 5 D.R/TP
R201,525,533
0RH1001C622
1K 1/16W 5 D.R/TP
R203,367,401,414,521
0RH1001C622
1K 1/16W 5 D.R/TP
R204,258,410,415,549
0RH0000C622
0 1/16W 5 D.R/TP
R205,380
0RH1500C622
150 1/16W 5 D.R/TP
R206,516,517,550
0RH0472C622
47 1/16W 5 D.R/TP
R209,331,581,587,625
0RH4701C622
4.7K 1/16W 5 D.R/TP
R210,270,271,509,534
0RH1002C622
10K 1/16W 5 D.R/TP
R211,375
0RH3300C622
330 1/16W 5 D.R/TP
CDR2 harman/kardon
91
