8
FREQUENCY RESPONSE
Coaxial 1 20 Hz
With a 0 dBFS, 1 KHz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, record theOutput Voltage at FLand FR
speaker outputs tobe the0 dBr,1 KHz
Reference value. Set meter to read
Amplitude
,
with dBr units,
and a 10 Hz-500 KHz BW
.
Then,ch
dBr >-0.7 >-0.3
Coaxial 1 20 KHz
,
dBr >-3 >-2
Digital Input data is a 96 KHz sampling rate, 24 bit, no Pre-emphasis, PCM bitstream.
ⷍ
FRONT AMP SECTION
No DESCRIPTION INPUT UNIT
LIMIT NOMINAL
1
Dynamic Range
Coaxial 1
With a 0 dBFS, 1 KHz sinewave PCM bitstream,and Main Volume
at 20 dB belowMax, set meter to read THD+N Ampl, with dBr
units. Use 'A Weighting' filter, 10 Hz-80 KHz BW. Record the
Output Voltage at FL and FR speaker outputs to be the 0 dBr
Reference val
dB >90 >93
2
RESIDUAL NOISE
Coaxial 1
With Digital Generator amplitude at -999 dBFS (Generator turned
off), 1 KHz sinewavePCM bitstream, and Main Volumeat 20 dB
belowMax, set meter to read Amplitude,10 Hz-22 KHz BW. Take
Amplitude readings on both FL and FR Speaker Outputs.
mVrms <1 <0.8
Coaxial 1
With Digital Generator amplitude at -999 dBFS (Generator turned
off), 1 KHz sinewavePCM bitstream, and Main Volumeat 20 dB
belowMax, set meter to read Amplitude,10 Hz-80 KHz BW. Take
Amplitude readings on both FL and FR Speaker Outputs.
mVrms <1.5 <1
Coaxial 1
With Digital Generator amplitude at -999 dBFS (Generator turned
off), 1 KHz sinewavePCM bitstream, and Main Volumeat 20 dB
belowMax, set meter to read Amplitude,10 Hz-22 KHz BW. Take
Amplitude readings on both FL and FR Speaker Outputs.
mVpk <3 <2
3
TOTALHARMONIC
DISTORTION
Coaxial 1 20 Hz
With a 0 dBFS, 1 KHz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read THD+N , with % units.
Use 10 Hz-22 KHz BW. Read THD+N Ratio,
with dBr units on both FL and FR Speaker
Outputs.
% <0.25 <0.15
1KHz
With a 0 dBFS, 20 Hz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, set meter to read THD+N , with % units.
Use 10 Hz-22 KHz BW. Read THD+N Ratio,
with dBr units on both FL and FR Speaker
Outputs.
% 0.6 0.4
REMARK
10
With a 0 dBFS, 1 KHz sinewave PCM
bitstream, andMain Volumeat 20 dB below
Max, record theOutput Voltage at FLand FR
speaker outputs tobe the0 dBr,1 KHz
Re
with dBr units,
and a 10 Hz-500 KHz BW.
fe
Then,ch
rence value. Set meter to read
Amplitude
DPR1001 harman/kardon
DETAILED SPECIFICATIONS (CONT'D)
